Takeuchi TB138FR Compact Excavator Workshop Manual (CG5E001) (SN 13810003-)

On a TB138FR that spends its life trenching along foundations, working in tight streets, or cleaning up around utilities, this workshop manual is what I’d keep open on the bench. It walks you through how to strip, inspect, and correctly reinstall the major components so the machine goes back to work without comebacks. If, for example, you’re chasing a weak boom lift or a slow swing, this is the book you use to trace the hydraulic circuit, verify settings, and reassemble everything in the right order.

Applications & Use Cases

• Plan a full repair sequence before tearing down major components like swing, boom, or travel systems.
• Trace hydraulic faults methodically instead of guessing at pumps, valves, or cylinders.
• Inspect wear points and decide what can be reused, resealed, or must be replaced.
• Verify correct reinstallation of hoses, linkages, guards, and panels after repairs.
• Support scheduled services with consistent checks so the excavator stays reliable on tight sites.

FAQ

Q: Can I use this manual on a tablet in the field?

A: Yes, it’s practical to keep it on a tablet; you can zoom diagrams and search terms while standing at the machine.

Q: Is it worth printing sections of this manual?

A: Printing the procedures you use often is handy—you can mark notes, tape pages to the cab, and not worry about grease on your device.

Safety Note

Always follow the manual’s lockout, support, and pressure-release steps before opening or removing any component.

Takeuchi TB138FR Compact Excavator Index:

I . GENERAL
II . SPECIFICATIONS
III . MACHINE CONFIGURATION
IV . HYDRAULIC UNITS
V . TROUBLESHOOTING
VI . ENGINE
