Takeuchi TB138FR Compact Excavator Workshop Manual (CG6E009) (SN 13820001-)

The TB138FR usually lives in tight spots—street repairs, utility trenches, working up against walls—so access is never great and mistakes get expensive fast. This workshop manual is what I’d pull out when I need the correct sequence to strip, inspect, and reinstall major components without guesswork. If, for example, the upper structure starts slewing rough or tight, I’d use this book to trace the issue through the swing system, verify clearances, and then reassemble everything in the right order so it tracks straight and swings smoothly again.

Applications & Use Cases

• Planning a major teardown of the boom, swing, or undercarriage, following the proper removal and reinstallation order.
• Tracing hydraulic faults—like weak travel or slow boom—by checking components in a logical, step‑by‑step way.
• Inspecting wear points on pins, bushings, and slew components so you don’t miss hidden damage.
• Verifying adjustments after repairs, ensuring controls respond correctly and the machine sits level and stable.
• Confirming torque, routing, and sealing practices before you button up critical joints and hose runs.

FAQ

Q: Is this manual practical to use on a tablet in the field?

A: Yes, it’s fine on a tablet; just bookmark key sections so you can jump straight to the systems you’re working on.

Q: Should I still print pages if I have the digital file?

A: For dirty jobs, I print the procedures and diagrams I need, mark them up as I go, then update any notes back in the digital copy later.

Safety Note

Always lock out the machine, support all raised components securely, and bleed stored pressure before loosening any major component.

Takeuchi TB138FR Compact Excavator Index:

• REVISION HISTORY
• FOREWORD
• I . GENERAL
• II . SPECIFICATIONS
• III . MACHINE CONFIGURATION
• IV . HYDRAULIC UNITS
• V . TROUBLESHOOTING
• VI . ENGINE
