Takeuchi TB175 Hydraulic Excavator Operators Manual (AL3E016) (SN 17512105-)

On a TB175 that spends its days trenching, loading trucks, or working around foundations on uneven, crowded jobsites, this operators manual is what I keep handy to run the machine the way it was meant to be run. It walks you through what each control does, how the excavator should feel under load, and what to check every day so you don’t beat up the hydraulics or undercarriage. If, for example, the swing feels jumpy when you’re slewing a full bucket near a building, this is the book I’d use first to verify operating procedures and basic checks before calling it a failure.

Applications & Use Cases

• Train new operators on proper control use, travel habits, and working on slopes without overloading the machine.
• Plan daily inspections so you can spot leaks, loose hardware, or track issues before they shut you down.
• Adjust operating technique for tight spaces, poor visibility, or soft ground to keep the machine stable and productive.
• Understand machine behavior when lifting, slewing, or tracking to avoid shock-loading components.
• Reduce premature wear on boom, bucket, and tracks by using the correct digging and backfilling methods.

FAQ

Q: Can I keep this manual on a tablet in the cab?

A: Yes, it’s practical to use digitally; you can zoom diagrams and search quickly, but protect the device from dust and vibration.

Q: Is it worth printing parts of it?

A: Many of us print the daily checks and operating diagrams, laminate them, and keep them in the site office or service truck for quick reference.

Safety Note

Always follow the manual’s operating guidance before working near people, traffic, trenches, or overhead hazards.

Takeuchi TB175 Hydraulic Excavator Index:

CONTENTS
Introduction ……………………………… 2
Machine Description …………………. 3
Safety ………………………………………. 7
Controls …………………………………..35
Operation …………………………………63
Transport …………………………………91
Maintenance …………………………….95
Troubleshooting ……………………..141
Specifications …………………………155
Options ………………………………….181
Index ……………………………………..221
