Takeuchi TS60R Skid Steer Parts Manual (0404-497) (REV 040516 SN 00101-)

Out on a construction site or in a muddy yard, that TS60R skid steer is doing the ugly work—grading, loading, backfilling, squeezing into tight spots. This parts manual doesn’t teach you how to drive it; it helps you trace every nut, bolt, and snap ring in the machine so you can order the right stuff the first time. Picture this: you’ve got the right final drive on the bench, seals out, and you’re staring at two nearly identical snap rings—this book lets you isolate the right one by assembly breakdown and part number, instead of guessing and waiting a week for the wrong part.

Applications & Use Cases

• Track down the exact hydraulic fitting or hose by routing diagram when you’ve got a leak but can’t see where the line disappears in the frame.
• Verify which bucket pins, bushings, and hardware match your serial range before you place an order.
• Inspect an exploded view of the final drive to test your diagnosis and make sure you’re not missing a hidden thrust washer or shim.
• Check alternate part numbers when something’s been superseded, so you can actually get what the dealer can still supply.
• Align your shelf stock with what fails most often—filters, seals, hardware—by seeing how assemblies break down into sub-components.

FAQ

Q: Is this a PDF I can search, or just page images?

A: It’s typically a searchable PDF, so you can jump by part number or description instead of flipping like a phone book.

Q: Can I print just a few pages to take to the machine?

A: Yeah, you can usually print whatever sections you need, then toss the greasy copies and keep the original file clean.

Safety Note

Always bleed off hydraulic pressure and secure the machine safely before you crack any lines or start pulling components.

Takeuchi TS60R Skid Steer Index:

• UNDERCARRIAGE 38
• FINAL DRIVE ASSEMBLY, RT 39
• FINAL DRIVE ASSEMBLY, LT 42
• MAINFRAME 44
• CHASSIS ASSEMBLY 45
• HOOD ASSEMBLY 50
• CAB/HEATING/AIR CONDITIONING 52
• R.O.P.S (CAB) ASSEMBLY 53
• CAB DOOR/WINDOWS 58
• R.O.P.S (CAB) HEADLINER/DASH PANEL 62
• R.O.P.S (CAB) INTERIOR 66
• WINSHIELD WIPER 69
• CAB HEATER (OPTIONAL) SEE SERIAL # BREAK 72
• AIR CONDITIONING/HEATING (OPTIONAL) 74
• AIR CONDITIONING/HEATING UNIT 78
• WORKING EQUIPMENT 80
• MANUAL QUICK ATTACH ASSEMBLY 81
• POWER QUICK ATTACH ASSEMBLY 84
• SAFETY DECALS -US (ANSI) 86
• SAFETY DECALS -US (ANSI) 87
• SAFETY DECALS -ROW (ISO) 90
