Takeuchi TS80R2 Skid Steer Loader Operation and Maintenance Manual (0404-509) (SN 00900-)

The TS80R2 is a mid-size skid steer you’ll see loading trucks, grading pads, and cleaning up rubble in dusty, muddy job sites. This Operation and Maintenance Manual is what I’d keep handy to set up a solid service rhythm, so the loader starts every morning and doesn’t surprise you mid-shift. When you’ve got something like a rough-running machine after a week in wet clay, this book helps you walk through basic checks—filters, lubrication points, daily inspections—so you can isolate simple issues before they turn into downtime.

Applications & Use Cases

• Plan preventive maintenance intervals so you grease, change filters, and inspect wear items before they fail.
• Walk a new operator through proper warm-up, shutdown, and operating habits that keep the loader predictable.
• Trace early warning signs like unusual noises, leaks, or sluggish hydraulics back to likely maintenance points.
• Verify adjustment and inspection steps after a repair so you know the machine is safe to send back to work.
• Confirm correct service points and access panels when you’re working in tight conditions or poor lighting.

FAQ

Q: Can I keep this manual on a tablet in the cab?

A: Yes, it works well digitally—you can zoom diagrams and search terms, which speeds up checks in the field.

Q: Is it worth printing parts of it?

A: I’d print the routine service and inspection pages, laminate them, and hang them in the shop for quick reference.

Safety Note

Always lock out, support, and relieve system pressure before inspecting or servicing this loader.

Takeuchi TS80R2 Skid Steer Loader Index:

Introduction …………………………………………….. 2
Safety ………………………………………………….. 5
Technical Data ………………………………………… 29
Machine Description / Controls………………….. 35
Operation ……………………………………………….. 55
Transportation…………………………………………. 65
Maintenance …………………………………………… 71
California Proposition 65 ………………………….. 90
