Takeuchi TW60 Wheel Loader Parts Manual (8016564) (08-08-07 SN E104062)

A TW60 wheel loader usually lives in the rough stuff—yards, sites, ag work—bouncing between piles, forks, and tight turns. This parts manual helps you trace every assembly on the machine down to the last seal and snap ring so you order the right piece the first time. Picture this: you’ve got the front lift frame stripped, pins out, bushings on the bench, and you can’t tell which grease seal matches that worn groove—this book lets you isolate the exact sub‑assembly, verify the part number, and move on.

Applications & Use Cases

• Track down which hydraulic hose you actually need by following the routing diagram and matching fittings before you crack anything loose.
• Break the front axle or steering section into sub‑components so you can inspect, test, and replace just the bearings or shims instead of guessing at a full unit.
• Identify the correct snap ring or spacer in the driveline when you’re halfway into a hub and don’t want to pull it apart twice.
• Cross‑check superseded part numbers with your dealer so you can verify you’re not ordering an old style that won’t align or fit.
• Plan a full pin-and-bushing job by grouping parts per joint, so you can route your order and schedule downtime once, not three times.

FAQ

Q: Is this a searchable PDF or just page images?

A: It’s typically a standard PDF; you can usually keyword search by part name or section, but plan on scrolling diagrams to visually match parts.

Q: Can I print just the sections I need for the shop?

A: Yes, most folks print the pages for the area they’re tearing down, stick them in plastic sleeves, and keep the clean master file on a laptop or office PC.

Safety Note

Always bleed off hydraulic pressure and secure the loader arms with proper supports before you inspect or remove any components in the lifting or steering circuits.
