Takeuchi TW65 Wheel Loader Parts Manual (8027384) (SN E110301 REV 053013)

A TW65 wheel loader usually lives in the dirt—construction sites, yards, snow work, tight urban jobs. This parts manual helps you trace every assembly on the machine down to the last washer, so you can order the right stuff the first time. Say you’ve got the loader apart chasing a sloppy center pivot; this book lets you isolate which bushings, shims, and seals belong to your serial range instead of guessing at the counter.

Applications & Use Cases

• Track down the exact snap ring or seal in the transmission or axle by following the exploded views and part-number breakdowns.
• Verify you’re ordering the right variant of a cylinder, hose, or valve block when Takeuchi used multiple designs on similar TW65s.
• Isolate sub-components in the lift and steering hydraulics so you don’t buy a whole assembly when you only need a spool or rod end.
• Route hoses and lines correctly after a teardown by matching the diagrams to what you’re seeing on the machine.
• Inspect wear items—pins, bushings, filters—by name and location, then build a proper parts list before you tear into the job.

FAQ

Q: Is this a searchable PDF or just scanned pages?

A: It’s typically a PDF you can search by part name or number, which makes tracing assemblies a lot quicker than flipping blind.

Q: Can I print pages to take out to the jobsite?

A: Yeah, most folks print the sections they need, stick them in a sleeve, and mark them up while they test, align, and reassemble.

Safety Note

Always lock out, block up, and bleed any stored hydraulic pressure before you start pulling components the manual helps you identify.

Takeuchi TW65 Wheel Loader Index:

LIFTING UNIT (8003072) 1
BASE FRAME (8002532) 4
STEERING HYDRAULICS (8011561) 10
WORKING HYDRAULICS (8011945) 13
RETURN HYDRAULICS (8017507) 16
TRAVEL HYDRAULICS (8017454) 19
HYDRAULIC LIFTING UNIT (8017642) 22
HYDRAULIC SYSTEM QRC (8016545) 24
PILOT CONTROL (COMPLETE) (8017492) 26
DIRECTIONAL VALVE 3-FOLD (8017657) 30
SERVO CONTROL BRACKET (8026893) 32
VALVE (COMPLETE) (8011331) 34
BRAKE THROTTLE VALVE (8028041) 36
WORKING CYLINDER (8017566) 38
LIFTING CYLINDER (8017548) 40
STEERING CYLINDER (3959515) 42
RETURN FILTER (8008817) 44
ELECTRICAL SYSTEM (8008690) 46
ELECTRICAL SYSTEM (CABIN) (8024503) 52
PRINTED CIRCUIT BOARD (8008597) 56
TRACTION DRIVE (8017415) 58
DIESEL ENGINE (COMPLETE)(8011116) 60
EXHAUST SYSTEM (8008274) 64
INCHING ACUTATOR (COMPLETE)(8024842) 66
AIR FILTER SYSTEM (3944347) 68
OIL PRESSURE PUMP (COMPLETE)(8017230) 70
OIL PRESSURE PUMP (12V) (8016978)-1 72
OIL PRESSURE PUMP (12V) (8016978)-2 74
OIL MOTOR (12V) (COMPLETE) (8016981) 76
FRONT AXLE (8006363)-1 78
FRONT AXLE (8006363)-2 82
REAR AXLE (MULTIPLE DISK BRAKE) (8006364)-1 84

REAR AXLE (MULTIPLE DISK BRAKE) (8006364)-2 88
FUEL SYSTEM (8008536) 92
DRIVERS SEAT (UPPER) (8008016)-1 94
DRIVERS SEAT (LOWER) (8008016)-2 96
PARTS CABIN ASSY (8026885) 98
CABIN COVERING (INSIDE & OUT)(8024496) 100
CABIN MOUNTING (COMPLETE) (8006546) 103
DAMPING MATERIAL SET (CAB) (8026886) 106
PANES KIT (8024501) 108
SET OF DOORS (8024464) 110
WIPER SYSTEM (8024836) 114
STEERING COLUMN (8024839) 116
HYDRAULIC QUICK RELEASE (8003071) 118
VENTILATION SYSTEM (8024507) 122
DECALS & ACCESSORIES (8016611) 126
PROTECTIVE HOSES (8016644) 130
FILTER SET (8018983) 132
COVERING (8011730) 134
ENGINE HOOD (COMPLETE) (8048052) 138
WHEELS & TIRES 140
MAINTENANCE FILTER KITS 142
BLOCK HEATER 144
TW FILTER CHART 146
