Volvo L120 BM Wheel Loader Parts Manual

^

Format: PDF (Printable Document)

File Language: English

File Pages: 882

File Size: 72.25 MB (Speed Download Link)

Brand: Volvo

Model: L120 BM Wheel Loader

Type of Document: Parts Manual

Categories: ,

Description

Volvo L120 BM Wheel Loader Parts Manual

Volvo L120 BM Wheel Loader Index:

(0) GENERAL
(2) ENGINE WITH MOUNTING AND EQUIPMENT
21 20 Repair kits
21 50 Engine with fitting parts
21 100 Cylinder block
21 150 Crankshaft and related parts
21 200 Camshaft
21 250 Timing gear casing and gears
21 300 Cylinder head
21 350 Engine mounting
22 50 Lubricating oil system
22 100 Oil pump
22 125 Oil cooler
22 150 Oil filter
22 200 Housing, oil filter
22 250 Oil filler and dipstick
23 50 Fuel system
23 100 Fuel pipes, fuel injection pump – fuel filter
23 150 Fuel lines, injectors
23 200 Fuel tank
23 250 Fuel filter
23 300 Injection pump with drive
23 350 Injection pump
23 400 Centrifugal governor
23 450 Smoke limiter
23 500 Feed pump
23 550 Injector
23 600 Slurry separator
23 650 Extra fuel filter 90656, IRAN
25 50 Inlet system
25 100 Air filter
25 150 Exhaust system
25 200 Turbocharger with fitting parts
25 250 Turbo charger STD
25 300 Oil bath filter 90677
25 350 Air filter
25 400 Pre cleaner cyclone type 90943
26 50 Cooling system
26 100 Radiator with fitting parts
26 125 Fan shroud STD USA
26 150 Belt transmission
26 200 Water pump and thermostat housing
26 250 Cooling system oil cooler
26 300 Coolant filter STD USA SER NO-60652
26 325 Coolant filter STD USA SER NO 60653
26 350 Intercooler 91151, 91351
26 400 Inlet manifold 91151, 91351
27 50 Regulator control
(3) ELEC. SYSTEM; WARNING SYSTEM; INFORMATION SYSTEM; INSTRUMENTS
31 50 Battery with assembling details
31 100 Battery box
32 50 Alternator with assembling details
32 110 Alternator
32 150 Brushles alternator 50a 91467
32 200 Alternator
33 50 Starter motor
35 50 Lighting
35 100 Lighting STD USA, 98274, 98275,
35 150 Headlamp
35 200 Rotating beacon 99886
35 205 Rotating beacon 99886
35 225 License plate lamp 90645
35 250 Protection front lighting 90617
36 50 Windscreen wiper, horn, reverse-motion alarm
36 100 Windshield wiper
36 150 Windshield washer
36 400 Comfort drive control, electrical system 91222
36 425 Cable harness for Cdc-steering 91880
36 450 Auxiliary steering system 90768
37 50 Electrical system, cab
37 60 Kickdown function 91641
37 65 Kickdown function 91952
37 100 Electric system front
37 125 Bucket automatic and lift automatic
37 150 Electric system rear
37 200 Electrical distribution box
37 300 Parking brake 90674
37 350 Starter element
37 400 Pre-heater
37 450 90317
37 500 Attachment locking; electrical system 91271, 91634
37 550 suspension
37 600 Cable harness
37 650 harness 5 th function 90819
38 50 Instrument panel
38 100 Instrument panel and instruments
38 150 Tacometer speedometer 91485
38 200 Instruments panel 91475, 91477
(4) POWER TRANSMISSION
41 40 Repair kit
41 50 Torque converter SER NO-5154, 5162-5167
41 100 Torque converter
41 110 Torque converter
42 50 Hydraulic transmission with fitting parts
42 100 Converter housing with assembly parts
42 150 Clutch housing with fitting parts
42 200 Clutches, gears and shafts
42 250 Clutches forward and reverse
42 300 Clutches 1 st and 2 nd speeds
42 350 Clutches 3 rd and 4th speeds HT – 6139
42 360 Clutches 3 rd and 4th speeds HT 6140
42 400 Hydraulic lines, valves and filter
42 450 Gear selector valve
42 500 Valves
42 550 Transmission pump
42 600 Valves
42 650 Pump drive
43 50 Dropbox housing and cover
43 100 Transfer gearbox gears and shafts
43 150 Gear box housing with fitting parts
45 50 Propeller shafts with fitting parts
45 100 Propeller shaft
45 150 Propeller shaft
46 50 Driveshafts with assembly parts
46 100 Drive axle, front
46 150 Final drive, front
46 200 Differential lock
46 250 Hydraulic system
46 300 Drive axle, rear
46 350 Final drive, rear
49 50 Cooling system
(5) BRAKE
51 40 Brake
51 50 Disc brake
52 50 Hydraulic brake system oil tank-foot brake valve
52 60 Hydraulic brake system oil tank foot brake valve
52 75 Hydraulic brake system footbrake valve – wheel
52 100 Tank with fitting parts
52 150 Pump with fitting parts
52 200 Relief valve with fitting parts
52 225 Relief valve with fitting parts
52 250 Footbrake valve with mountings
52 300 Manometer with fitting parts
52 350 Pump
52 375 Pump
52 400 Valves
52 450 Footbrake valve CAB – 13278, (USA) CAB – 61641
52 460 Footbrake valve CAB 13279 (USA) CAB 61642-, IRAN
52 500 Dual brake pedals 90730
55 50 Parking brake
55 100 Disc brake
55 150 Hydraulic parking brake 91195, 91635
56 50 Compressed air equipment 91269, 91701
56 100 Air compressor 91269, 91701
56 150 Regulator 91269, 91701
56 200 Anti-freezer reservoir 91306
56 250 Anti-freezer reservoir
56 300 Air pressurized shafts 91352
(6) STEERING
64 50 Steering system
64 60 Steering system SER NO 6825 6889, (USA) SER NO 60502-60507
64 70 Steering system
64 80 Valves
64 90 Steering cylinder
64 100 Steering column with fitting parts
64 150 Steering unit
64 200 Valve body
64 250 Valves
64 300 Hydraulic cylinder
64 325 Hydraulic pump
64 330 Hydraulic pump
64 350 Adjustable steering wheel (USA), 33230, 90667 91310
64 400 Comfort drive control 91222
64 450 Control valve, comfort drive control 91222
64 460 Comfort drive control 91880
64 475 Valves 91880
64 500 Auxiliary steering system 90768
64 525 Pump unit 90768
64 550 Valves 90768
(7) FRAME;SPRINGS;DAMPING;AXLE SUSPENSION; WHEEL TRACK UNIT
71 50 Frame
71 400 Protecting plates
77 50 Wheel 90734, 90796 – 90800, 91500 – 91503
77 75 Wheel 91505 – 6, 91508 – 91510, 91515, 98308, 98310 – 12
77 100 Wheel 98313 – 98314
77 150 Wheel 91289,91504,91507,91511,91516,92014,97874,99178,9985
77 200 Rim 91285
(8) MACHINERY HOUSE;CAB;EXTERIOR TRIM PARTS ANYWHERE
81 50 Operator’s cab
81 100 Cab body
82 50 Engine hood
82 100 Side hatches
82 150 Radiator casing
82 200 Front- and rear mudguards
82 250 Full-coverage mudguard 90646
82 300 Dust guard 90930
82 350 Protection for fuel inlet 90971
83 50 Door
83 100 Door 90883
84 50 Glass panes and interior components
84 75 Windows CAB 8184-10852, (USA) CAB 60403-61170, IRAN CAB-50350
84 90 Windows CAB 10853 -, (USA) CAB 61171 -, IRAN CAB 50351
84 100 Ventilation pane STD USA,
84 150 Rear view mirror
85 50 Insulating matting
85 100 Operator seat with fitting parts CAB – 7420
85 125 Operator seat with fitting parts CAB 7421 – , (USA), IRAN, 90683, 90883, 90939, 90940
85 150 Operator’s seat
85 165 Operator’s seat
85 175 Driver’s seat, air suspensioned, heated 91643
85 185 Driver’s seat, air suspensioned, heated 91643
85 200 Seat 90143
85 300 Comfort drive control, foldable arm rest 91222
85 350 Cdc-steering plate details 91880
86 50 Bottom-guard plates 91037
87 50 Radiator with fitting parts CAB – 7942, (USA) CAB – 60344
87 75 Radiator with fitting parts CAB 7943 – . (USA) CAB 60345 – ,
87 100 Controls CAB – 7942, (USA) CAB – 60344
87 125 Controls CAB 7943-13753, (USA) CAB 60345-61715, IRAN CAB -50633
87 130 Controls CAB 13754 -.
87 150 Air ducts CAB – 7942, (USA) CAB – 60344
87 175 Air ducts CAB 7943
87 200 Fan CAB – 13753, (USA) CAB – 61715, IRAN CAB – 50633
87 210 Fan CAB 13754 – , (USA) CAB 61716 – ,
87 250 Heating system, hoses
87 300 Air conditioning 90553,
87 350 Air-compressor with fitting parts 90553, 91199
87 400 Condenser with fitting parts 90553,
87 450 Evaporator with fitting parts 90553,
87 500 Condenser 90553, 91199
87 550 Air compressor 90553,
87 600 Extra air outlett cab ventilation 91251
88 50 Radio panel 99717 CAB – 9127,
88 100 Radio panel 91305 CAB 9128 –
89 50 Tools
89 100 Sign plates and decals
89 125 Sign plates and decals
89 135 Sign plates and decals USA
89 150 Slow moving vehicle sign 99592
89 200 Tyre-inflating equipment RAN SER NO – 50613
(9) HYDRAULIC SYSTEM;DIGGING HANDLING GRADING EQUIPM.; MISC. EQUIP
91 50 Feed lines
91 100 Lifting system
91 150 Tilting system
91 200 Hydraulic tank
91 225 Hydraulic pump
91 230 Hydraulic pump
91 250 Filter
91 300 Hydraulic cylinder lifting
91 350 Hydraulic cylinder tilting
91 400 Control valve SER NO -6679, USA SER NO -60478, IRAN SER NO -50362
91 450 Control valve SER NO 6680-, USA SER NO 60479-, IRAN SER NO 50363-
91 600 Relief valve
91 650 Servo-system feed lines SER NO -6889, USA SER NO -60507, IRAN SER NO -50362
91 675 Servo-system feed lines SER N9,6890 – USA SER NO 60508 -, IRAN SER NO 50363-
91 700 Servo-system control lines
91 750 Servo-system servo valve
91 775 Assembly parts for servo valve
91 800 Lever lock STD USA
91 850 Lever lock 90522
91 900 3 rd function 90609
91 950 3rd and 4 th function 90608
91 975 Extra hydraulic equipment3rd and 4th function 91275, 91672
91 1000 5th function 90819
91 1050 Boom lowering system STD USA, 90746
91 1100 Valves SER NO – 6294
91 1110 Valves SER NO 6295 –
91 1120 Single-acting lifting function 90773
91 1150 Oil cooler
91 1175 Attachment locking 91271,
91 1200 Automatic hose coupling (ahc) 91320 SER NO – 6551
91 1250 Automatic hose coupling (ahc) 91320 SER NO 6552
91 1300 Automatic hose coupling (ahc) 91320
91 1350 Control cylinder 91320
91 1400 Boom suspension system 91826
91 1450 Valves 91826
92 50 Hydraulic attachment bracket 90423,
92 100 Hydraulic cylinder
93 50 Engine heater 90678
94 50 Lifting unit 33312 SER NO – 6479, USA, IRAN
94 75 Lifting unit 33312 SER NO 6480
94 100 Links with fitting parts 33312 SER NO – 6479, USA, IRAN
94 125 Loading unit 33329
94 150 Lifting framework 33329
94 200 Lubricating kit 91639
E 91 920 Extra hydraulic equipment3rd hydraulic control 91273
