Weidemann 1025 D-P Hoftrac Parts Catalog (5056102505)

On a small Weidemann Hoftrac like the 1025 D/P, you’re usually working in tight farmyards, stables, or landscaping jobs where downtime hurts. This parts catalog is what I’d lay on the bench when I’m tracing a hydraulic leak or freshening up the loader after a hard season. It lets you visually break the machine down, match what’s in front of you to the correct exploded view, and then pick the exact seals, pins, and brackets you need. For example, if a lift cylinder is weeping, this book helps you identify the right seal kit and any backup rings or bushings that are easy to overlook.

Applications & Use Cases

• Trace assemblies on the boom, axles, and chassis to see how each component stacks and orients.
• Verify small parts like shims, snap rings, and O-rings so they’re not missed during reassembly.
• Differentiate part revisions when there were design changes mid-production.
• Confirm hardware sizes and types before tearing down, so you can pre-order bolts, nuts, and washers.
• Check filter and hose variants to avoid mixing early and later style components.

FAQ

Q: Can I use this catalog on a tablet in the workshop?

A: Yes, it’s practical to keep it open on a tablet so you can zoom in on exploded views right next to the machine.

Q: Is it worth printing certain pages?

A: Many techs print just the assemblies they’re working on and mark them up with notes and quantities during the job.

Safety Note

Always verify parts with the machine’s identification plate and follow the official safety instructions before starting any work.

Weidemann 1025 D-P Hoftrac Index:

7-8 Wichtige Hinweise Important Notices Notices Importantes Observaciones Importantes
10-11 Filtersatz filter set jeu de filtres juego de filtros
1 12-17 Vorder-und Hinterwagen Chassis Chassis Chasis
2 18-19 Mittelgelenk Central joint Pivot Centrale Rótula central
20-21 Trittplatte Running Board Planche De Marche Pied Estribo
3 22-29 Motorhaube und
Überrollbügel
roll bar ceinture de sécurité à
enrouleur
antivuelco
4 30-33 Schwinge MV loading arm MV bras chargeur MV brazo de cargo MV
34-37 Schwinge HV loading arm HV bras chargeur HV brazo de cargo HV
5 38-59 Motor und Anbauteile Engine and parts Moteur y piezas motor
60-63 Auspuff und Luftfilter exhaust and air filter echapement et filtre Escape y filtro de aire
64-67 Gasbetätigung accelerator accelerateur acelerador
68-71 Gasbetätigung 1025 Spezial Accelerator 1025 Spezial Accelerateur 1025 Spezial Acelerador 1025 Spezial
72-73 Inchbetätigung 1025 Spezial Inch control 1025 Spezial Commande 1025 Spezial Actividad 1025 Spezial
6 74-79 Kraftstoffanlage fuell system systema de cambustile sistema de carburante
7 80-95 Elektrische Anlage Electric system Système électrique Sistema eléctrica
96-103 Armaturenkasten Instrument box Boite des instrumentes Caja de instrumentos

104-106 Stromlaufplan Electrical wiring diagramme Schéme de couplage électriq. Diagrama de circuito eléctrico
108-109 Hydrauliklaufplan Hydraulic wiring diagramme Schéme de couplage hydr. Diagrama de circuito hidráulico
110-115 Verstellpumpe Variable Displacement Pump Pompe A Debit Variable Bomba De Caudal Variable
8 116-143 Fahrhydraulik Driving hydraulic Transmission hydraul. Trsanmission hidráulica
9 144-159 Lenkanlage Steering system Système de direction Sistema de conducción
10 160-169 Hydraulikanlage MV DN 10 Hydraulic system MV DN 10 Système hydraulique MV Sistema hidráulica MV DN 10
170-179 Hydraulikanlage HV DN 10 Hydraulic system HV DN 10 Système hydraulique HV Sistema hidráulica HV DN 10
11 180-183 Kreuzsteuerventil I Cross Steering valve I distributeur hydraul. I válvula de mando en cruz I
184-187 Kreuzsteuerventil II Cross Steering valve II distributeur hydraul. II válvula de mando en cruz II
12 188-193 Bremsanlage Brake system Système des freins Sistema de frenos
194-197 Achsantrieb vorn K80 Front gear box Boite de vitesse av. Caja de cambios del.
198-203 Achsantrieb hinten K80 Rear gear box Boite de vitesse ar. Eje delantera
204-207 Achsantrieb vorn K90 Front gear box Boite de vitesse av. Caja de cambios del.
208-213 Achsantrieb hinten K90 Rear gear box Boite de vitesse ar. Eje delantera
14 214-217 Erdschaufel Bucket earth Godet Cuchara de tierra
218-229 Krokodilgebiß Crocodile teeth Fourche crocodile Pinza crocodilo
230-233 Palettengabel Pallet forks Palettiseur Horquillas de palet
