Weidemann 1055 D/P Wheel Loader Parts Catalog

Format: PDF (Printable Document)

File Language: English

File Pages: 271

File Size: 12.64 MB (Speed Download Link)

Brand: Weidemann

Model: 1055 D-P Wheel Loader

Type of Document: Parts Catalog

Categories: PDF, Weidemann

$ 45

Weidemann 1055 D/P Wheel Loader Parts Catalog

Weidemann 1055 D-P Wheel Loader Parts Catalog

On a Weidemann 1055 D/P wheel loader that spends its life loading buckets, handling pallets, and working around yards or farms, this parts catalog is what I’d keep open whenever I’m rebuilding or chasing a damaged component. It helps you pinpoint the exact parts in each assembly so you don’t guess at seals, shims, or hardware. For example, if you bend a loader arm pin or crack a linkage bushing, this catalog lets you trace that whole joint, confirm every washer and seal, and order the correct revision instead of finding out something doesn’t fit when the machine is already stripped.

Applications & Use Cases

Use the exploded views to see how pins, bushings, and spacers stack up in the loader arms and linkage.
Isolate the correct hydraulic cylinder variant when there are multiple designs for the same mounting points.
Verify small parts—O-rings, snap rings, grease fittings, shims—that are easy to overlook during disassembly.
Cross-check part numbers before ordering so you don’t mix early and late design revisions.
Print specific pages to keep by the machine while you strip and reassemble a component.

FAQ

Q: Can I use this catalog on a tablet in the workshop?

A: Yes, it’s practical to zoom into the diagrams on a tablet, which makes reading small part callouts much easier.

Q: Is it worth printing sections of this catalog?

A: Many techs print the assemblies they’re working on so they can mark notes, circle parts, and keep it next to the machine without worrying about dirt or grease on a device.

Safety Note

Always verify parts with the machine identification plate and follow the manufacturer’s safety procedures before starting any repair.

📘 Show Index

Weidemann 1055 D-P Wheel Loader Index:

11-12 Wichtige Hinweise Important Notices Notices Importantes Observaciones Importantes
14-15 Filtersatz filter set jeu de filtres juego de filtros
1 16-21 Vorder-und Hinterwagen Chassis Chassis Chasis
2 22-25 Mittelgelenk Central joint Pivot Centrale Rótula central
3 26-29 Trittplatte Rubber Running Board Planche de Marchepied
caoutchouc
Estribo de goma
30-37 Motorhaube engine bonnet capot capot
38-39 Dämmatten Insulation Material Panneaux isolants Esterillas de insonorizacion
4 40-43 Schwinge MV loading arm MV bras chargeur MV brazo de cargo MV
44-47 Schwinge HV loading arm HV bras chargeur HV brazo de cargo HV
48-51 Schwinge MV HH loading arm MV HH bras chargeur MV HH brazo de cargo MV HH
52-55 Schwinge HV HH loading arm HV HH bras chargeur HV HH brazo de cargo HV HH
5 56-63 Motor engine moteur motor
64-71 Motor 1055 Spezial Sauer Engine 1055 Spezial Sauer Moteur 1055 Spezial Sauer Motor 1055 Spezial Sauer
72-79 Motor 1055 Spezial
Hydromatik
Engine 1055 Spezial
Hydromatik
Moteur 1055 Spezial
Hydromatik
Motor 1055 Spezial Hydromatik
6 80-83 Auspuff und Luftfilter exhaust and air filter echapement et filtre Escape y filtro de aire

84-87 Drehzahlverstellung +
Gasbetätigung
Revolution Adjustment +
accelerator
Changement de vitesse +
accelerateur
Ajuste de velocidad + acelerador
90-93 Kraftstoffanlage fuell system systema de cambustile sistema de carburante
7 94-97 Elektrische Anlage ohne
Beleuchtung Sauer
Electric system without
lighting Sauer
Système électrique sans
illumination Sauer
Sistema eléctrica sin alumbrado
Sauer
98-101 Elektrische Anlage mit
Beleuchtung Sauer
Electric system with lighting
Sauer
Système électrique avec
illumination Sauer
Sistema eléctrica con alumbrado
Sauer
102-105 Elektrische Anlage ohne
Beleuchtung Hydromatik
Electric system without
lighting Hydromatik
Système électrique sans
illumination Hydromatik
Sistema eléctrica sin alumbrado
Hydromatik
106-111 Elektrische Anlage mit
Beleuchtung Hydromatik
Electric system with lighting
Hydromatik
Système électrique avec
illumination Hydromatik
Sistema eléctrica con alumbrado
Hydromatik
112-115 Armaturenlenksäule starr Dashboard stiff Tableau de bord raide Tablero de mando rigido
116-119 Armaturenlenksäule Dashboard Tableau de bord Tablero de mando
120 Stromlaufplan ohne
Beleuchtung
Electrical wiring diagramme
without lighting
Schéme de couplage électriq.
Sans illumination
Diagrama de circuito eléctrico sin
alumbrado
121 Stromlaufplan mit
Beleuchtung
Electrical wiring diagramme
with lighting
Schéme de couplage électriq.
Avec illumination
Diagrama de circuito eléctrico
con alumbrado
122 Hydrauliklaufplan Hydraulic wiring diagramme Schéme de couplage
hydraulique
Diagrama de circuito hidráulico
123 Hydrauliklaufplan 1055
Spezial
Hydraulic wiring diagramme
1055 Spezial
Schéme de couplage
hydraulique 1055 Spezial
Diagrama de circuito hidráulico
1055 Spezial

página
Benennung parts name designation Denominación
124-125 Verstellpumpe 42 R 28 Variable Displacement Pump
42 R 28
Pompe à débit variable
42R28
Bomba de caudal variable 42R28
126-129 Verstellpumpe A10 VG28 Variable Displacement Pump
A10 VG28
Pompe à débit variable A10
VG28
Bomba de caudal variable A10
VG28
8 130-139 Fahrhydraulik 1055 D/P Driving hydraulic 1055 D/P Transmission hydraul. 1055
D/P
Trsanmission hidráulica 1055
D/P
140-149 Fahrhydraulik 1055 Spezial
Sauer
Driving hydraulic 1055 Spezial
Sauer
Transmission hydraul. 1055
Spezial Sauer
Trsanmission hidráulica 1055
Spezial Sauer
150-159 Fahrhydraulik 1055 Spezial
Hydromatik
Driving hydraulic 1055 Spezial
Hydromatik
Transmission hydraul. 1055
Spezial Hydromatik
Trsanmission hidráulica 1055
Spezial Hydromatik
9 160-167 Lenkanlage Steering system Système de direction Sistema de conducción
168-175 Lenkanlage 1055 Spezial Steering system 1055 Spezial Système de direction 1055
Spezial
Sistema de conducción 1055
Spezial
10 176-181 Hydraulikanlage MV Hydraulic system MV Système hydraulique MV Sistema hidráulica MV
182-187 Hydraulikanlage MV HH Hydraulic system MV HH Système hydraulique MV HH Sistema hidráulica MV HH
188-195 Hydraulikanlage HV Hydraulic system HV Système hydraulique HV Sistema hidráulica HV
196-203 Hydraulikanlage HV HH Hydraulic system HV HH Système hydraulique HV HH Sistema hidráulica HV HH
204-211 Hydraulikanlage HV (2
Dreiwegehähne)
Hydraulic system HV (2
Dreiwegehähne)
Système hydraulique HV (2
Dreiwegehähne)
Sistema hidráulica HV (2
Dreiwegehähne)
212-219 Hydraulikanlage HV HH (2
Dreiwegehähne)
Hydraulic system HV HH (2
Dreiwegehähne)
Système hydraulique HV HH
(2 Dreiwegehähne)
Sistema hidráulica HV HH (2
Dreiwegehähne)

220-221 Kreuzsteuerventil I Cross Steering valve I distributeur hydraul. I válvula de mando en cruz I
12 222-227 Bremsanlage Brake system Système des freins Sistema de frenos
13 228-235 Vorderachse + Hinterachse
KPY86
Front axle + rear axle KPY86 Essieu avant + essieu arriere
KPY86
Eje delantera + eje trasero
KPY86
236-243 Vorderachse + Hinterachse
KPY86 ab 03/98
Front axle + rear axle KPY86
from 03/98
Essieu avant + essieu arriere
KPY86 de 03/98
Eje delantera + eje trasero
KPY86 del 03/98
244-251 Vorderachse + Hinterachse
KPY106
Front axle + rear axle KPY106 Essieu avant + essieu arriere
KPY106
Eje delantera + eje trasero
KPY106
252-257 Achsantrieb K90 gear box K90 Boite de vitesse K90 Caja de cambios K90
14 258-261 Erdschaufel Bucket earth Godet Cuchara de tierra
262-267 Krokodilgebiß Crocodile teeth Fourche crocodile Pinza crocodilo
268-271 Palettengabel Pallet forks Palettiseur Horquillas de palet
