Weidemann 1060 D-P Wheel Loader Parts Catalog

This Weidemann 1060 D/P wheel loader parts catalog is what I reach for when the machine’s been working in tight farm yards, feedlots, or construction sites and something finally gives up. The loader does a lot of pallet work, bucket work, and general handling, so pins, bushings, hoses, and seals wear. This catalog helps you pinpoint exactly which parts belong on your specific 1060 D/P, so you don’t guess at fittings or order the wrong linkage hardware. For example, if a lift cylinder starts weeping or a steering joint gets sloppy, I use this book to trace the assembly, confirm every seal and bushing, and make sure all the small bits are on the order list.

Applications & Use Cases

• Identify correct part numbers for boom, axle, and steering components when you’re rebuilding worn joints.
• Compare different revisions of the same component to avoid mixing early and late-style parts.
• Verify small hardware like shims, circlips, and O-rings that are easy to overlook during teardown.
• Check exploded views to see how subassemblies stack together before you strip or reassemble them.
• Plan a full repair kit so you don’t miss a seal or bushing and have to stop mid-job.

FAQ

Q: Can I use this catalog on a tablet in the workshop?

A: Yes, it works well on a tablet; you can zoom in on the exploded views to read part numbers and see small details.

Q: Is it worth printing certain pages?

A: I usually print the assemblies I’m working on, mark them with notes and grease smudges, then keep them with the job folder.

Safety Note

Always isolate the machine, relieve hydraulic pressure, and follow lockout procedures before removing or installing any parts.

Weidemann 1060 D-P Wheel Loader Index:

9-10 Wichtige Hinweise Important Notices Notices Importantes Observaciones Importantes
12-13 Filtersatz filter set jeu de filtres juego de filtros
1 14-19 Vorder- und Hinterwagen Front And Rear Chassis Chassis avant et arriere Chasis delantera y trasera
2 20-23 Mittelgelenk Central joint Pivot Centrale Rótula central
3 24-33 Haube und Trittplatte Bonnet, running board Bonnet, planche de Capot, estribo
34-35 Dämmatten Insulating material Materiel isolant
marchepied
Material de insonorizacion
4 36-39 Schwinge MV 915 Loading arm MV 915 Bras chargeur MV 915 Brazo de cargo MV 915
40-43 Schwinge HV 920 Loading arm HV 920 Bras chargeur HV 920 Brazo de cargo HV 920
44-47 Schwinge MV 918
Hohe Hubhöhe
Loading arm MV 918
High hight
Bras chargeur MV 918
Haut levée hauteur
Brazo de cargo MV 918
Alto carrera altura
48-51 Schwinge HV 921
Hohe Hubhöhe
Loading arm HV 921
High hight
Bras chargeur HV 921
Haut levée hauteur
Brazo de cargo HV 921
Alto carrera altura
5 52-59 Motor engine Moteur Motor
60-63 Auspuff und Luftfilter Exhaust and air filter Echapement et filtre Escape y filtro de aire
64-67 Drehzahlverstellung und
Gasbetätigung
Revolution Adjustment and
Accelerator
Changement de vitesse et
accelerateur
Ajuste de velocidad y acelerador
68-71 Inchbetätigung inch control commande actividad

Weidemann
