Format: PDF (Printable Document)
File Language: it, es, en
File Pages: 557
File Size: 8.28 MB (Speed Download Link)
Brand: Weidemann
Model: 2070CX80LP Tele Wheel Loader
Book No: 2070CX80LPT_06_2008
Type of Document: Spare Parts Catalog
$ 45
This tele wheel loader usually lives in tight farmyards, feed alleys, and construction sites, doing pallet work, stacking bales, and loading material all day. This catalog is what I’d keep open when I’m stripping down the boom or front axle and need to be sure every pin, shim, and seal goes back with the right replacement. If, for example, the telescopic boom starts leaking or feels loose, I’d use this book to trace the exact cylinder version, boom sections, wear pads, and hose routings before I order anything.
Applications & Use Cases
FAQ
Q: Can I use this catalog on a tablet in the workshop?
A: Yes, it’s practical to zoom into the exploded views on a tablet, which helps when matching parts on a dirty machine.
Q: Is it worth printing sections of this catalog?
A: Many techs print the pages for the area they’re working on, then mark notes and part choices directly on the sheet.
Safety Note
Always verify parts visually on the machine and follow the loader’s official safety procedures before disassembly.
