Weidemann 2070CXLP T Telescopic Loader Spare Parts Catalog

Format: PDF (Printable Document)

File Language: it, es, en

File Pages: 920

File Size: 34.24 MB (Speed Download Link)

Brand: Weidemann

Model: 2070CXLP T Telescopic Loader

Book No: 2070CX

Serial No: 3026784 – …

Type of Document: Spare Parts Catalog

Categories: PDF, Weidemann

$ 45

Weidemann 2070CXLP T Telescopic Loader Spare Parts Catalog

Weidemann 2070CXLP T Telescopic Loader Spare Parts Catalog (2070CX) (3026784 – …) (it, es, en)

This catalog is what I’d keep open on the bench whenever we’re working on a 2070CXLP T telescopic loader in farm yards, feedlots, or tight construction sites. The machine is constantly lifting, loading, and stacking, so pins, bushings, hoses, and wear parts get tired. This document helps you pinpoint the exact parts layout, so you don’t guess. For example, if the telescope boom starts leaking at one of the stages, I’d use this to trace the cylinder assembly, confirm every seal and wiper, and make sure we order the right revision of the rod and hardware.

Applications & Use Cases

Identify correct boom and linkage parts when repairing sloppy pivots or worn bushings.
Trace hydraulic lines and fittings to isolate a leak and match the correct hose variant.
Verify hardware and small components—washers, circlips, shims—that are easy to miss during reassembly.
Compare different part revisions so you don’t mix old and updated components on the same assembly.
Build accurate parts orders before teardown, reducing downtime while the loader is parked.

FAQ

Q: Can I use this catalog on a tablet in the workshop?

A: Yes, it’s practical to zoom into the exploded views on a tablet, then print key pages if you want them next to the machine.

Q: Is this useful if I only do basic maintenance?

A: Definitely; it helps you confirm the right filters, seals, and service kits so you don’t order the wrong parts.

Safety Note

Always lock out, support, and depressurize the machine before inspecting or replacing any components shown in this catalog.
