Format: PDF (Printable Document)
File Language: English
File Pages: 273
File Size: 6.92 MB (Speed Download Link)
Brand: Weidemann
Model: 2502 BL D-D Baggerlader
Type of Document: Parts Catalog
$ 45
On a Weidemann 2502 BL D/D backhoe loader that spends its life in mud, feed yards, or on construction sites, this parts catalog is what I’d keep open when I’m rebuilding or chasing damage. It helps you pin down the exact part variant from the exploded views so you don’t guess at pins, bushings, seals, or hardware. If, for example, you’ve bent a loader arm and blown a couple of hoses, this book lets you trace the whole assembly, see every fitting and seal stack, and order everything you need in one go instead of tearing it down twice.
Applications & Use Cases
FAQ
Q: Can I use this catalog on a tablet in the field?
A: Yes, as long as the file opens on your tablet, you can zoom in on the exploded views to identify parts right at the machine.
Q: Is it worth printing sections of this catalog?
A: Many techs print the pages for the area they’re working on, mark them with notes or measurements, and keep them with the job card for easier reassembly.
Safety Note
Always lock out the machine, support raised components securely, and depressurize hydraulic circuits before inspecting or replacing any parts.
9-10 WICHTIGE HINWEISE IMPORTANT NOTICES NOTICES IMPORTANTES OBSERVACIONES IMPORTANTES
12-13 FILTERSATZ FILTER SET JEU DE FILTRES JUEGO DE FILTROS
1 14-19 VORDER- UND HINTERWAGEN FRONT AND REAR CARRIAGE PARTIE AVANT ET ARRIERE PARTE DELANTERA Y TRASERA
2 20-25 MITTELGELENK CENTRAL JOINT PIVOT CENTRALE RÓTULA CENTRAL
3 26-29 TRITTPLATTE RUNNING BOARD POSTE DE CONDUITE ESTRIBO
30-35 KABINE CABIN CABINE CAPÓ
36-41 STANDHEIZUNG HEATING CHAUFFAGE CALEFACCION
42-45 DIESELHEIZUNG I DIESEL HEATING I CHAUIFFAGE MAZOUT I CALEFACCION DIESEL I
46-49 DIESELHEIZUNG II DIESEL HEATING II CHAUIFFAGE MAZOUT II CALEFACCION DIESEL II
4 50-53 SCHWINGE 908 LOADING ARM 908 BRAS CHARGEUR 908 BRAZO DE CARGA 908
54-57 SCHWINGE 910 LOADING ARM 910 BRAS CHARGEUR 910 BRAZO DE CARGA 910
5 58-63 MOTOR UND ANBAUTEILE ENGINE AND PARTS MOTEUR ET PIECES MOTOR Y PIEZAS
64-65 HANDGASBETÄTIGUNG HANDGAS SYSTEM SYST. D’ACCELERATEUR A MAIN SISTEMA DEL ACELERADOR A MANO
66-69 AUSPUFFANLAGE EXHAUST SYSTEM SYSTEME D’ECHAPPEMENT SISTEMA DE ESCAPE
70-73 KRAFTSTOFFANLAGE FUEL SYSTEM SYSTEME DE CARBURANT SISTEMA DE CARBURANTE
6 74-81 ELEKTRISCHE ANLAGE ELECTRIC SYSTEM DIAGRAMME SYSTEME ELECTRIQUE SISTEMA ELECTRICO
82-87 ARMATURENKASTEN INSTRUMENT BOX BOITE DES INSTRUMENTS CAJA DE INSTRUMENTOS
88-93 ARMATURENTAFEL DASHBOARD TABLEAU DE BORD TABLERO DE MANDO
8 94-97 VERSTELLPUMPE A4VG40DA VARIABLE DISPLACEMENT PUMP
A4VG40DA
POMPE A DEBIT VARIABLE
A4VG40DA
BOMBA DE CAUDAL VARIABLE
A4VG40DA
98-101 VERSTELLPUMPE A4V40DA VARIABLE DISPLACEMENT PUMP
A4V40DA
POMPE A DEBIT VARIABLE
A4V40DA
BOMBA DE CAUDAL VARIABLE
A4V40DA
102-103 INCHBETÄTIGUNG INCH CONTROL COMMANDE ACTIVIDAD
104-113 FAHRHYDRAULIK DRIVING HYDRAULIC TRANSLATION HYDRAULIQUE TRASLACION HIDRAULICO
9 114-123 LENKANLAGE STEERING SYSTEM SYSTEME DE DIRECTION SISTEMA DE CONDUCCION
10 124-133 HYDRAULIKANLAGE STANDARD I
DN10
HYDRAULIC SYSTEM STANDARD I
DN 10
SYSTEME HYDRAULIQUE
STANDARD I DN10
SISTEMA HIDRÁULICA STANDARD I
DN10
134-145 HYDRAULIKANLAGE HOHE
HUBHÖHE II DN10
HYDRAULIC SYSTEM
HIGH HIGHT II DN10
SYSTEME HYDRAULIQUE HAUT
LEVEE HAUTEUR II DN10
SISTEMA HIDRÁULICA ALTO
CARRERA ALTURA II DN10
146-149 KREUZSTEUERVENTIL SD 5/3 CROSS STEERING VALVE SD 5/3 DISTRIBUTEUR HYDRAUL. SD 5/3 VALV. DE MANDO EN CRUZ SD 5/3
11 150-157 BREMSANLAGE BRAKE SYSTEM SYSTEME DES FREINS SISTEMA DE FRENOS
11 158-165 ACHSANTRIEB VORNE FRONT GEAR BOX BOITE DE VITESSE AVANT CAJA DE CAMBIOS DELANTERA
12 166-173 ACHSANTRIEB HINTEN REAR GEAR BOX BOITE DE VITESSE ARR. CAJA DE CAMBIOS TRASERA
174-183 MITTELSTÜCK VORN MIDDLE PART FRONT PARTIE CENTRALE AVANT PARTE CENTRAL DELANTERA
184-191 MITTELSTÜCK HINTEN MIDDLE PART REAR PARTIE CENTRALE ARRIERE PARTE CENTRAL TRASERA
192-195 ACHSROHR PLANETENTRÄGER AXLE TUBE PLANETARY SUPPORT ESSIEU DE ROUE SU.
PLANETAIRE
TUBO DE EJE SOPORTE PLANETARIO
196-197 ACHSROHR MIT
DIFFERENTIALSPERRE
AXLE TUBE WITH DIFFERENTIAL
LOCK
ESSIEU DE ROUE AVEC ROUE
BLOQUAGE DU DIFFERENTIEL
TUBO DE EJE CON BLOQUE DEL
DIFERENCIAL
13 198-201 VERSCHIEBUNG BAG.ARM TYP II ADJUSTING BAR TYPE TYPE II DECALAGE TYPE II BARRA DE AJUSTE TIPO II
202-205 VERSCHIEBUNG BAG.ARM TYP III ADJUSTING BAR TYPE TYPE III DECALAGE TYPE III BARRA DE AJUSTE TIPO III
14 206-211 DREHGELENK BAG.ARM TYP II SWIVEL JOINT EXCA. TYPE II JOINT TORNANT EXCA. TYPE II JUNTURA GIRATORIO EXCA. TIPO II
212-217 DREHGELENK BAG.ARM TYP III SWIVEL JOINT EXCA. TYPE III JOINT TORNANT EXCA. TYPE III JUNTURA GIRATORIO EXCA. TIPO III
15 218-221 ANBAUBAGGER TYP II BACKHOE TYPE II EXCAVATEUR TYPE II RETROEXCAVADORA TIPO II
222-227 ANBAUBAGGER TYP III BACKHOE TYPE III EXCAVATEUR TYPE III RETROEXCAVADORA TIPO III
16 228-237 HYDRAULIKA. DREHGELENK HYDR. SYSTEM SWIVEL JOINT SYSTEME HYDR. JOINT TORNANT SISTEMA HIDR. JUNTURA GIRATORIO
17 238-249 HYDRAULIKANLAGE BAGGERARM HYDRAULIC SYSTEM EXCAVATOR SYSTEME HYDRAULIQUE EXCAV. SISTEMA HIDRAULICA EXCAVADORA
250-255 STEUERVENTIL STEERING VALVE COMMANDE HYDR. EN CROIX VALVULA DE MANDO EN CRUZ
18 256-257 ERDSCHAUFEL EARTH BUCKET GODET CUCHARA DE TIERRA
258-263 UNI-SCHAUFEL 1500 BUCKET 1500 GODET 1500 CUCHARA 1500
264-265 PALETTENGABEL PALLET FORKS PALETTISEUR HORQUILLAS DE PALET
19 266-271 LÖFFEL ANBAUBAGGER TYP III BUCKET BACKHOE TYPE III GODET AXCAVATEUR TYPE III CUCHARA EXCAVADORA TIPO
