Weidemann 916 Hoftrac Parts Catalog

The Weidemann 916 Hoftrac usually lives in tight farmyards, stables, and small construction sites, doing loader work all day. This parts catalog is what I’d keep open whenever I’m rebuilding a joint, chasing a hydraulic leak, or sorting out a bent loading arm. For example, if the center joint starts to clunk, this book lets me break the assembly down on paper first, so I can see every seal, bushing, and spacer before I strip it on the floor.

Applications & Use Cases

• Trace assemblies like the chassis, central joint, and loading arm to see how each bracket, pin, and shim stacks together.
• Confirm small parts—O-rings, clips, washers—that are easy to overlook when ordering from memory.
• Differentiate part revisions so you don’t mix early and late-style components when replacing pins, cylinders, or panels.
• Verify hardware sizes before you start, so you’ve got the right bolts and bushings on hand during a tight downtime window.
• Plan rebuilds by checking what should be renewed while the machine is already stripped down.

FAQ

Q: Can I use this catalog on a tablet in the workshop?

A: Yes, it’s practical to zoom in on exploded views, then screenshot or mark the part numbers you need.

Q: Is it worth printing sections of this catalog?

A: Many techs print the pages for the area they’re working on and tape them to the machine for quick reference.

Safety Note

Always verify parts against the machine’s ID plate and follow the official service procedures before disassembly.
