Description
Atlas Copco ROC F7 CR Drilling Rig Parts Catalog
Atlas Copco ROC F7 CR Drilling Rig Index:
1. DRILL CARRIAGE / BORRVAGN …………………………………………………. 5
2. DRIVE UNIT / DRIVENHET ………………………………………………………… 79
3. BOOM SYSTEM / BOMSYSTEM ………………………………………………. 127
4. FEED / MATARE ……………………………………………………………………… 167
5. CABIN / HYTT …………………………………………………………………………. 243
6. AIR CONDITIONER / KLIMATANLÄGGN. ………………………………….. 317
7. DCT EQUIPMENT / DCT UTRUSTNING …………………………………….. 339
8. SIGN SET / SKYLTSATS ………………………………………………………….. 355
9. HYDR. RESERVOIR / HYDRAULTANK ……………………………………… 363
10. HYDR. SYSTEM / HYDRAULSYSTEM ………………………………………. 371
11. AIR SYSTEM / LUFTSYSTEM ………………………………………………….. 491
12. HOSE SET COMPL. / SLANGSATS KOMPL ……………………………… 547
13. HOSE CONNECTION / SLANGANSLUTNING …………………………… 561
14. ELECTR. SYSTEM / ELSYSTEM ……………………………………………… 581
15. CABLE SET / KABELSATS ……………………………………………………… 679
16. OPTION / OPTION ………………………………………………………………….. 683
17. CROSS REFERENCE LIST ……………………………………………………….. 751
