A V723 VersaHANDLER is the Bobcat telehandler you see loading seed, stacking pallets, or feeding bales where a skid or tractor just can't reach. The service manual is what a shop or field tech grabs when the boom won't lift, the hydraulics get weak, or an electrical fault keeps it from starting. Folks use this when they're past warranty and need real repair info, not safety stickers and button layouts.
What this manual helps you do
- Diagnose hydraulic and boom issues, trace oil flow, and pressure-test the lift/tilt/aux circuits on the V723.
- Check and set hydrostatic and driveline components when you've got weak travel, no drive, or noisy axles.
- Follow teardown and reassembly steps for cylinders, pumps, valves, and mechanical boom components.
- Troubleshoot electrical faults using wiring diagrams, connector callouts, and step-by-step test procedures.
- Verify adjustment specs and settings after you replace major parts so the machine runs like it should.
Who this is for
This is for a shop mechanic, small contractor, rental fleet, or owner-operator working on a Bobcat V723 VersaHANDLER TTC in the listed serial range. If you just need operating tips, capacities, or routine maintenance intervals, you want the operator's handbook, not this service manual.
FAQ
Q: Is this a searchable PDF, and can I read the wiring diagrams on a laptop?
A: These manuals are usually searchable PDFs, and the wiring diagrams are made to be zoomed so you can read pin numbers and wire colors.
Q: My V723 serial number starts with 36801, will this cover it?
A: If your machine's serial falls between 368011001 and 368099999, this is the correct manual. Outside that range, you need a different book.
Q: I'm just changing fluids and filters. Is this overkill?
A: Yes, this manual is more than you need for basic service. It's aimed at diagnostics and repairs, not quick maintenance.
Bottom line: If you have a Bobcat V723 VersaHANDLER TTC in that serial range and you're doing real repair work, this is the right service manual. If your serial is outside that range or you only want how-to-operate info, skip it.
📘 Show Index
Table of Contents:
- MAINTENANCE SAFETY
- ALPHABETICAL INDEX
- CONTENTS
- FOREWORD
- SAFETY INSTRUCTIONS
- SERIAL NUMBER LOCATION
- VersaHANDLER Serial Number
- Engine Serial Number
- Other Serial Numbers
- DELIVERY REPORT
- BOBCAT VersaHANDLER IDENTIFICATION
- SAFETY AND MAINTENANCE
- LIFTING AND BLOCKING THE VERSAHANDLER
- OPERATOR CAB/CANOPY
- Emergency Exit
- Cab Door
- Cab Door Window
- TRANSPORTING THE VersaHANDLER
- TOWING THE VersaHANDLER
- Procedure (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Procedure (For S/N 367812001 & Above, S/N 368012001 & Above, S/N 368112001 & Above)
- SERVICE SCHEDULE
- AIR CLEANER SERVICE
- ENGINE COOLING SYSTEM
- Cleaning The Cooling System
- Checking The Coolant Level
- Replacing The Coolant
- FUEL SYSTEM
- Fuel Specifications
- Filling The Fuel Tank
- Fuel Filter
- ENGINE LUBRICATION SYSTEM
- Checking Engine Oil
- Oil Chart
- Replacing Oil And Filter
- HYDRAULIC/HYDROSTATIC SYSTEM
- Checking And Adding Fluid
- Replacing Hydraulic/Hydrostatic Filter
- Replacing Hydraulic Fluid
- AXLES (FRONT AND REAR) (For S/N 367811001 – 367812000, S/N 368011001 – 368012000, S/N 36811001 – 368112000)
- Checking Oil Level (Planetary Carrier)
- Draining Oil (Planetary Carrier)
- Checking Oil Level (Rear Differential)
- Draining Oil (Rear Differential)
- Checking Oil Level (Front Differential)
- Draining Oil (Front Differential)
- AXLES (FRONT AND REAR) (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Checking Oil Level (Planetary Carrier)
- Draining Oil (Planetary Carrier)
- Checking Oil Level (Rear Differential)
- Draining Oil (Rear Differential)
- Checking Oil Level (Front Differential)
- Draining Oil (Front Differential)
- LUBRICATION (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Procedure
- Procedure (Cont’d
- LUBRICATION (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- TIRE MAINTENANCE
- Wheel Nuts (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- SPARK ARRESTOR MUFFLER
- APPROVED BOOM STOP
- Installing The Approved Boom Stop
- Removing The Approved Boom Stop
- ENGINE COVER
- Opening And Closing The Engine Cover
- LATERAL OPERATOR RESTRAINT SYSTEM (LORS™)
- System Inspection
- System Maintenance
- HYDRAULIC SYSTEM
- HYDRAULIC/HYDROSTATIC SCHEMATICS
- HYDRAULIC SYSTEM INFORMATION
- Troubleshooting Chart
- Tightening Procedures
- LIFT CYLINDER
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- BUCKET POSITIONING CYLINDER
- BUCKET POSITIONING CYLINDER (CONT’D)
- Parts Identification
- Disassembly
- Assembly
- EXTENSION CYLINDER
- Cylinder Group Removal And Installation
- Upper Tubeline Removal
- Upper Tubeline Installation
- Extension Cylinder Removal And Installation
- Tubeline Tray Disassembly
- Tubeline Tray Assembly
- Parts Identification
- Disassembly
- Assembly
- TILT CYLINDER
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- STEERING CYLINDER (FRONT) (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- STEERING CYLINDER (FRONT) (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Removing The Steering Cylinder
- Disassembling The Steering Cylinder
- Assembling The Steering Cylinder
- STEERING CYLINDER (REAR) (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- STEERING CYLINDER (REAR) (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Removing The Steering Cylinder
- Installing The Steering Cylinder
- Disassembling The Steering Cylinder
- Assembling The Steering Cylinder
- DRIVE BOX (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Parts Identification
- Disassembly
- Inspection
- Assembly
- DRIVE BOX (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Parts Identification
- Disassembly
- Assembly
- Special Tools
- MAIN RELIEF VALVE
- Testing And Adjustment
- Removal And Installation
- QUICK TACH CYLINDER
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- FRAME LEVELING CYLINDER
- Removal And Installation (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation (For S/N 367812001 & Above, S/N 368012001 & Above, S/N 368112001 & Above)
- Removal
- Parts Identification
- Disassembly
- Assembly
- STEERING MODE VALVE BLOCK
- Removal And Installation
- Parts Identification
- Disassembly
- Solenoid Testing
- Assembly
- BRAKE VALVE
- Removal And Installation
- Disassembly And Assembly
- GEAR PUMP
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- FAN MOTOR
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- HYDRAULIC RESERVOIR
- STEERING VALVE
- Removal And Installation
- Parts Identification
- Disassembly
- Inspection
- Assembly
- HYDRAULIC CONTROL VALVE
- Troubleshooting Chart (Controllers)
- Telescoping Valve Section Troubleshooting
- Auxiliary Valve Section Troubleshooting
- Troubleshooting Chart (Control Valve)
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- End Housing Disassembly And Assembly
- Lifting Valve Section Disassembly And Assembly
- Tilting Valve Section Disassembly And Assembly
- Telescoping Valve Section Disassembly And Assembly
- Auxiliary/Frame Leveling Valve Section Disassembly And Assembly
- Inlet-Outlet Valve Section Disassembly And Assembly
- PORT RELIEF VALVES
- FLOW CONTROL VALVE
- JOYSTICK
- PARKING BRAKE
- Pressure Switch Removal And Installation
- Pressure Switch Disassembly And Assembly
- Parking Brake Valve Removal And Installation
- Parking Brake Valve Disassembly And Assembly
- PRESSURE REDUCING VALVE
- Testing
- Removal And Installation
- Disassembly And Assembly
- ACCUMULATOR
- TOW VALVE
- Removal And Installation
- Disassembly And Assembly
- HYDROSTATIC SYSTEM
- HYDROSTATIC SYSTEM INFORMATION
- Troubleshooting Chart
- Replenishing Valve Function
- OIL COOLER
- HYDROSTATIC DRIVE MOTOR
- Removal And Installation
- Parts Identification
- Inspection
- Assembly
- HYDROSTATIC PUMP
- Removal And Installation
- Parts Identification
- Disassembly
- Inspection
- Assembly
- DRIVE SYSTEM
- TROUBLESHOOTING
- AXLE AND DIFFERENTIAL (FRONT) (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- General Information
- Planetary Carrier Parts Identification
- Planetary Carrier Disassembly
- Planetary Carrier Inspection
- Wheel Hub Parts Identification
- Wheel Hub Disassembly
- Wheel Hub Inspection
- Steering Knuckle Parts Identification
- Steering Knuckle Disassembly
- Axle Housing/Drive Axle Parts Identification
- Axle Housing/Drive Axle Disassembly
- Brake Group Parts Identification
- Brake Group Disassembly
- Brake Group Inspection
- Differential Parts Identification
- Differential Disassembly
- Differential Inspection
- Pinion Group Parts Identification
- Pinion Group Disassembly
- Pinion Group Inspection
- Pinion Group Assembly
- Differential Assembly
- Brake Group Assembly
- Axle Housing/Drive Axle Assembly
- Steering Knuckle Assembly
- Wheel Hub Assembly
- Planetary Carrier Assembly
- AXLE AND DIFFERENTIAL (REAR) (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- General Information
- Planetary Carrier Parts Identification
- Planetary Carrier Disassembly
- Planetary Carrier Inspection
- Wheel Hub Parts Identification
- Wheel Hub Disassembly
- Wheel Hub Inspection
- Steering Knuckle Parts Identification
- Steering Knuckle Disassembly
- Axle Housing/Drive Axle Parts Identification
- Axle Housing/Drive Axle Disassembly
- Differential Parts Identification
- Differential Disassembly
- Differential Inspection
- Pinion Group Parts Identification
- Pinion Group Disassembly
- Pinion Group Inspection
- Pinion Group Assembly
- Differential Assembly
- Axle Housing/Drive Axle Assembly
- Steering Knuckle Assembly
- Wheel Hub Assembly
- Planetary Carrier Assembly
- AXLE AND DIFFERENTIAL (FRONT) (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- General Information
- Planetary Carrier Parts Identification
- Planetary Carrier Disassembly
- Steering Knuckle And Drive Axle Parts Identification
- Steering Knuckle Disassembly
- Drive Axle Disassembly
- Brake System Identification
- Brake System Disassembly
- Differential Parts Identification
- Differential Disassembly
- Bevel Pinion Parts Identification
- Bevel Pinion Disassembly
- Bevel Pinion Assembly
- Differential Assembly
- Brake System Assembly
- Drive Axle Assembly
- Steering Knuckle Assembly
- Planetary Carrier Assembly
- Special Tools
- AXLE AND DIFFERENTIAL (REAR) (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- General Information
- Planetary Carrier Parts Identification
- Planetary Carrier Disassembly
- Steering Knuckle And Drive Axle Parts Identification
- Steering Knuckle Disassembly
- Differential And Bevel Pinion Parts Identification
- Differential Disassembly
- Bevel Pinion Disassembly
- Bevel Pinion Assembly
- Differential Assembly
- Steering Knuckle Assembly
- Planetary Carrier Assembly
- Special Tools
- FRONT AXLE WITHOUT FRAME LEVELING (For S/N 367811001 – 367812000)
- FRONT AXLE WITH FRAME LEVELING (For S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- AXLE PIVOT FRAME (S/N 367811001 – 367812000, S/ N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation
- Bushing Removal And Installation
- FRONT AXLE (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- AXLE TOE-IN (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- AXLE TOE-IN (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- PARKING BRAKE (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Releasing The Brake For Towing
- Re-Activating The Brake
- PARKING BRAKE (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Releasing The Brake For Towing
- Re-Activating The Brake
- STEERING ANGLE ADJUSTMENT (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- STEERING ANGLE ADJUSTMENT (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- DRIVESHAFT
- Removal And Installation (S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation (S/N 367812001 & Above, S/ N 368012001 & Above, S/N 368112001 & Above)
- SERVICE BRAKE (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Description
- Bleeding The Brake Circuit
- SERVICE BRAKE (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- Description
- Bleeding The Brake Circuit
- REAR AXLE (For S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- REAR AXLE (For S/N 367812001 and Above, S/N 368012001 and Above, S/N 368112001 and Above)
- MAIN FRAME
- OPERATOR CAB
- CANOPY
- OPERATOR SEAT
- BOOM ASSEMBLY
- INNER BOOM
- WEAR PADS (FRONT)
- WEAR PADS (REAR)
- ENGINE COVER
- Gas Cylinder Removal And Installation
- Removal And Installation
- AIR INTAKE COWLING
- FUEL TANK
- QUICK-TACH
- REAR WEIGHTS
- FENDER
- Removal And Installation (S/N 367811001 – 367812000, S/N 368011001 – 368012000 and S/N 368111001 – 368112000)
- Removal And Installation (S/N 367812001 & Above, S/ N 368012001 & Above, S/N 368112001 & Above)
- PIVOT LINK
- DASH COVER/STEERING COLUMN COVER
- JOYSTICK PANEL
- ELECTRICAL SYSTEM AND ANALYSIS
- ELECTRICAL SCHEMATICS
- ELECTRICAL SYSTEM INFORMATION
- Troubleshooting Chart
- Description
- Fuses, Diodes & Relays
- BATTERY
- Removal And Installation
- Servicing
- Using A Booster Battery (Jump Starting)
- ALTERNATOR
- Removal And Installation
- Adjusting The Alternator Belt
- STARTER
- Removal And Installation
- Disassembly
- Inspection And Repair
- Assembly
- LATERAL OPERATOR RESTRAINT SYSTEM (LOR’S™)
- Restraint Bar Removal And Installation
- Sensor Removal And Installation
- Strut Removal And Installation
- Strut Disassembly And Assembly
- Restraint Bar Bushing Removal And Installation
- Restraint Bar Bumper Removal And Installation
- LIGHTS
- Rear Light Removal And Installation
- Front Light Removal And Installation
- TRAVEL/SIGNAL LEVER
- INSTRUMENT PANEL
- SWITCH PANEL
- BRAKE LIGHT SWITCH
- Removal And Installation
- Adjustment
- FRONT WIPER MOTOR
- TOP WIPER MOTOR
- REAR WIPER MOTOR
- PEDAL ASSEMBLY
- Removal And Installation
- Disassembly And Assembly
- INCHING SWITCH
- Removal And Installation
- Adjustment
- SERVICE SOFTWARE
- Connecting The Laptop Computer
- Entering The Service Software
- Monitor Screen
- Warnings Screen
- Calibrate Inch Pedal
- Calibrate Creep Potentiometer
- Program/Update Susmic Controller
- FRAME LEVEL SPEED SWITCH
- Description
- Removal
- Installation
- Disassembly And Assembly
- ENGINE SERVICE
- TROUBLESHOOTING
- ENGINE SPEED CONTROL
- MUFFLER
- AIR CLEANER
- Housing Removal And Installation
- OIL COOLER/RADIATOR
- Removal And Installation
- Disassembly And Assembly
- ENGINE AND ENGINE MOUNTS
- ENGINE COMPONENTS AND TESTING
- Fuel Injection Pump Removal
- Fuel Injection Pump Installation
- Fuel Injectors Removal And Installation
- Checking The Fuel Lift Pump
- Fuel Lift Pump Removal And Installation
- Compression Checking
- Glow Plugs Checking
- Glow Plugs Removal And Installation
- ENGINE TIMING
- ENGINE/HYDROSTAT ASSEMBLY
- FLYWHEEL AND HOUSING
- Removal And Installation
- Ring Gear Removal
- Ring Gear Installation
- RECONDITIONING THE ENGINE
- Turbo Charger Troubleshooting
- Turbo Charger Description
- Turbo Charger Removal And Installation
- Exhaust Manifold Removal And Installation
- Fuel Injector Cover Removal And Installation
- Rocker Cover Removal And Installation
- Cylinder Head Removal
- Cylinder Head Inspection
- Cylinder Head Installation
- Rocker Shaft Disassembly And Assembly
- Valve Removal
- Valve Springs Checking
- Valve Depth Checking
- Valve Guides Checking
- Valve Guide Removal
- Valve Guide Installation
- Valves Checking
- Cutting A Valve Seat
- Valve Seat Assembly
- Changing Valve Springs (With Cylinder Head Installed)
- Valve Clearance Adjustment
- Timing Case And Drive Assembly Description
- Timing Cover Removal
- Timing Cover Installation
- Crankshaft Pulley Removal And Installation
- Front Oil Seal Removal And Installation
- Timing Case And Gear Removal
- Timing Case And Gear Installation
- Camshaft And Tappets Removal
- Camshaft And Tappets Installation
- Pistons And Connecting Rods Description
- Pistons And Connecting Rods Removal
- Pistons And Connecting Rods Disassembly
- Piston Ring End Gap
- Piston Ring Installation
- Piston Ring Groove Clearance
- Connecting Rod Inspection
- Connecting Rod Bushing Replacement
- Piston And Connecting Rod Assembly
- Piston And Connecting Rod Installation
- Checking Piston Height
- Crankshaft And Bearings Description
- Crankshaft And Bearings Removal
- Inspection Of Crankshaft And Bearings
- Crankshaft And Bearings Installation
- Rear Oil Seal Removal
- Rear Oil Seal Housing Positioning
- Rear Oil Seal Installation
- Checking Crankshaft End Play
- Cooling System Description
- Thermostat Removal and Installation
- Thermostat Testing
- Lubricating Oil Cooler Removal And Installation
- Water Pump Removal
- Water Pump Installation
- Engine Lubrication System Description
- Oil Filter Adapter Removal And Installation
- Oil Pan Removal And Installation
- Oil Screen And Pick-up Tube
- Oil Pump Removal
- Oil Pump Installation
- Oil Pump Disassembly And Assembly
- Oil Pressure Relief Valve Disassembly And Assembly
- Engine Block Description
- Engine Block Disassembly And Assembly
- Piston Cooling Jet Removal
- Piston Cooling Jet Installation
- Piston Cooling Jet Alignment
- Inspection
- Cylinder Liner Inspection
- Cylinder Liner Removal
- Cylinder Liner Installation
- HEATING, VENTILATION, AIR CONDITIONING
- AIR CONDITIONING SYSTEM FLOW
- COMPONENTS
- SAFETY
- REGULAR MAINTENANCE
- Filter Element Removal And Installation
- Compressor Drive Belt Inspection
- Cleaning The Condenser
- BASIC TROUBLESHOOTING
- Poor A/C Performance
- Compressor Drive Belt Inspection
- Checking The Electrical System
- GENERAL AIR CONDITIONING SERVICE GUIDELINES
- Compressor Oil
- Compressor Oil Check
- Component Replacement And Refrigeration Leaks
- SYSTEM TROUBLESHOOTING CHART
- TEMPERATURE/PRESSURE
- AIR CONDITIONING SERVICE
- SYSTEM CHARGING AND RECLAMATION
- Reclamation Procedure
- Charging Procedure With A Manifold Gauge Set
- Charging Procedure
- COMPRESSOR
- Removal And Installation
- Compressor Clutch Disassembly And Assembly
- CONDENSER
- RECEIVER/DRIER
- PRESSURE SWITCH
- EVAPORATOR/BLOWER UNIT
- EXPANSION VALVE
- HEATER ASSEMBLY
- Removal And Installation
- Fan Removal And Installation
- Core Removal And Installation
- SPECIFICATIONS
- VersaHANDLER SPECIFICATIONS
- Dimensional Specifications
- Performance Specifications
- Engine
- Controls
- Drive System
- Tires
- Capacities
- Hydraulic System
- Electrical System
- Instrument Panel
- ENGINE SPECIFICATIONS
- General
- Cylinder Head
- Valve Guides
- Exhaust Valves
- Intake Valves
- Valve Springs
- Rocker Shaft, Rockers And Bushings
- Pistons And Piston Rings
- Connecting Rods And Bearings
- Crankshaft
- Crankshaft Re-Grind Data
- Main Bearings
- Thrust Washers
- Camshaft And Thrust Washer
- Cylinder Block
- Cylinder Liners
- Fuel Injection Pump
- Fuel Injectors
- Fuel Lift Pump
- Timing Case And Timing Gears
- Oil Pump, Gear And Relief Valve
- Turbocharger
- Flywheel
- Water Pump And Thermostat
- Engine Torque Component
- MACHINE TORQUE SPECIFICATIONS
- Axle
- Boom
- Drive Box
- Drive Motor
- Engine
- Hydraulic Pump
- TORQUE SPECIFICATIONS FOR BOLTS
- Torque for General SAE Bolts
- Torque For General Metric Bolts
- HYDRAULIC CONNECTION SPECIFICATIONS
- O-ring Face Seal Connection
- Straight Thread O-ring Fitting
- Tubelines And Hoses
- Flare Fitting
- O-ring Flare Fitting
- Port Seal Fitting
- HYDRAULIC/HYDROSTATIC FLUID SPECIFICATIONS
- CONVERSIONS
- Decimal And Millimeter Equivalents
- U.S. To Metric Conversion Chart
- SMR
- V723-1
- V723-2
- V723-3
- V723-4
- V723-5
- V723-6
Bobcat Software
Bobcat PDF Manuals
