Case CX42D, CX45D, CX50D, CX55D Mini Excavator Service Manual (92293079)

These CX42D–CX55D minis usually live in tight jobsites—utility trenches, residential foundations, landscaping—where downtime hurts fast. This service manual is what I’d pull out when I need to trace a hydraulic issue, split components safely, or verify adjustments after a repair. If, for example, the boom starts drifting down under load, this book walks you through a logical path: check the simple stuff first, then isolate the suspect circuit, test components, and only then tear into a valve or cylinder.

Applications & Use Cases

• Track and undercarriage work – inspect wear, disassemble travel motors, and reassemble without guessing seal orientation.
• Hydraulic troubleshooting – trace slow functions or weak digging power using step-by-step checks instead of random parts swapping.
• Engine-related service – route hoses and wiring correctly after repairs and verify basic settings so it starts and runs right.
• Swing, boom, and arm repairs – align pins, bushings, and cylinders and confirm free movement after rebuilds.
• Electrical diagnostics – isolate sensor or switch faults by following a structured test approach.

FAQ

Q: Can I use this manual on a tablet in the field?

A: Yes, it’s practical on a tablet; you can zoom diagrams while you’re standing at the machine.

Q: Is it worth printing sections?

A: For messy jobs like hydraulic teardown, printing just the relevant pages keeps your main copy clean and right at the bench.

Safety Note

Always lock out, support, and relieve all stored energy on the excavator before you loosen, disconnect, or test anything.

Case CX42D, CX45D, CX50D, CX55D Mini Excavator Index:

INTRODUCTION
Engine – 10
Hydraulic systems – 35
Frames and ballasting – 39
Tracks and track suspension – 48
Cab climate control – 50
Electrical systems – 55
Booms, dippers, and buckets – 84
Dozer blade and arm – 86
Accessories – 88
Platform, cab, bodywork, and decals – 90
92293078EN
92293072EN
92293076EN
92300535EN
92300536EN

CNH
