Case Liquid System 610 Applicator Operator Manual (92031485)

This operator manual is what we lean on to run a Case Liquid System 610 applicator correctly in real field conditions—row crops, uneven ground, long days chasing weather windows. It walks you through how to start, shut down, and monitor the system so you don’t scorch pumps, over-pressurize lines, or misapply product. If, for example, your rate suddenly looks off or a boom section won’t respond, this is the book you use to trace what the operator controls are telling the system and verify you’re not missing a simple setup or startup step.

Applications & Use Cases

• Confirm correct startup and shutdown so pumps, valves, and hoses aren’t shocked or run dry.
• Guide daily walk‑around checks to catch leaks, loose fittings, or worn hoses before they fail in the field.
• Verify control settings when rate, pressure, or section control doesn’t behave as expected.
• Train new operators on what each switch and display actually does, reducing costly misapplication.
• Reinforce safe filling and flushing habits to protect the machine, the operator, and the crop.

FAQ

Q: Can I keep this manual on a tablet in the cab?

A: Yes, a digital copy works well; just make sure it’s downloaded so you can search it without cell service.

Q: Is it worth printing certain pages?

A: Many techs print the startup, shutdown, and daily inspection pages and keep them in a plastic sleeve on the machine.

Safety Note

Always follow the manual’s shutdown and depressurization steps before opening or disconnecting any part of the liquid system.

Case Liquid System 610 Applicator Index:

GENERAL INFORMATION
Read the Operator’s Manual
CNH Industrial America LLC technical manuals
Your applicator
Note to the owner
Applicator intended use
Electro-Magnetic Compatability (EMC)
Manual scope and required training level
Product identification
Operator’s manual storage
Machine orientation
Component location
SAFETY INFORMATION
Safety rules
Safety rules
Ecology and the environment
Hand signals
Safety rules and signal word definitions
Safety signs
CONTROLS AND INSTRUMENTS
RIGHT-HAND SIDE CONTROLS
INSTRUMENT CLUSTER
WORKING OPERATIONS
GENERAL INFORMATION
BOOM OPERATION
SPRAY SYSTEM
MAINTENANCE
GENERAL INFORMATION
MAINTENANCE CHART
Every 10 hours or daily
Every 50 hours
Every 200 hours
Every 250 hours
Every 500 hours
As required maintenance
STORAGE
TROUBLESHOOTING
FAULT CODE RESOLUTION
SYMPTOM(S)
SPECIFICATIONS
General specification

CNH
