Caterpillar EP15KRT Forklift Service Manual (99759-65110)

This Cat EP15KRT is an electric counterbalanced forklift for moving pallets around warehouse aisles, loading areas, and charger bays. When a truck is pulled from service during a shift, a maintenance tech uses this manual to test the fault, remove components, and get the truck working again. I'd reach for it for second-shift breakdowns, electrical faults, hydraulic work, or a drive-unit repair.

What this manual helps you do

• Trace wiring, switches, sensors, and controller circuits during electrical faults.
• Check and diagnose the traction motor, controller, battery, and charging-related systems.
• Follow removal and refitting procedures for the drive unit, axles, brakes, and steering parts.
• Troubleshoot hydraulic functions, mast operation, forks, and related control components.
• Adjust and service the truck using its listed specifications, test methods, and repair procedures.

Who this is for

This suits a warehouse maintenance tech, dealer technician, independent forklift shop, plant maintenance team, or rental fleet mechanic working on Cat electric trucks. It is a workshop service manual for the forklift trade, with the operator handbook available as the companion volume for daily truck operation.

FAQ

Q: What do I receive, and how is it organised?

A: You receive 15 PDF files split by section, with 363 pages total. The files can be searched and copied from, and the PDF pages can be printed or zoomed for workshop use.

Q: Which truck does it cover?

A: It covers the Caterpillar EP15KRT, serial coverage ETB10-50001-up. That gives you a direct match for this model and serial range.

Q: How does it fit the repair job?

A: It is the shop-level reference for diagnosing and repairing the EP15KRT electric forklift, including electrical systems, traction drive, hydraulics, mast, steering, and brakes. It gives a technician the procedures and service data needed to work through repairs in-house.

For a Cat EP15KRT in that serial range, this is the manual to use for planned repairs and breakdown work, from wiring checks to major component removal.

Models covered by this manual

Caterpillar publication 99759-65110 is the factory service manual for the EP15KRT, serial range ETB10-50001-up. The same publication covers 2 further forklift models: EP10KRT, EP12KRT. Check the model and serial number on your data plate before ordering.

Table of Contents:

• ATT 1 SW
• LIFT
• GND
• BACKWARD SW
• SEAT SW
• ACCEL ENABLE SW
• LINE CTR GND
• SERVICE BRAKE SW
• AUX 1 SW
• GND
• ACCELERATOR
• BACKUP BUZZER
• V 500 A max
• V to 4 V
• V at power ON
• V after the contactor is in operation. If contactor
