Caterpillar EP20 72-80V MCIII Forklift Electrical Schematic (99759-60100)

On a plant floor, the Cat EP20 electric counterbalanced truck moves pallets, racks, and production loads through warehouse work. When wiring faults stop it, plant maintenance techs and forklift electricians reach for this manual to find the circuit, test the right points, and get the truck running before the repair window closes. This publication is for EP16, EP18, EP20, EP25, and EP30 trucks in the listed 36/48V and 72/80V versions.

What this manual helps you do

• Trace full circuit routing from components through connectors and harnesses.
• Check connector pin assignments, wire numbers, and wire colours during fault finding.
• Diagnose electrical problems using the included diagnostic tables.
• Verify circuits at the traction motor, controller, switches, sensors, and truck controls.
• Troubleshoot intermittent wiring faults before replacing sound components.

Step-by-step mechanical repair procedures are in the companion service manual, also available.

Who this is for

This suits a warehouse maintenance tech, dealer technician, independent forklift repair shop, rental fleet mechanic, or plant maintenance electrician working on Cat electric counterbalanced trucks. It is the trade reference for electrical fault finding, while the companion chassis service manual and operator handbook cover their own jobs.

FAQ

Q: What do I receive, and how is it organised?

A: You receive 2 PDF files, 182 pages total, split by section. That gives you the schematic material in a manageable set for workshop or field use.

Q: Which truck variants and serials does it cover?

A: It covers EP16, EP18, EP20, EP25, and EP30 MCIII trucks in the stated 36/48V and 72/80V configurations, with serial groups E1EP1-62001-up, E1EP1-82001-up, E1EP1-72001-up, E1EP1-87001-up, E1EP2-82001-up, and E1EP2-92001-up.

Q: How does it fit the repair job?

A: Use it when the truck has an electrical fault and you need to identify the circuit, connector, wire, or diagnostic path. It gives electricians the information needed to test safely and make a sound repair.

For a wiring fault on a covered Cat EP electric truck, this is the manual to have beside the meter during the repair.

Models covered by this manual

Caterpillar publication 99759-60100 is the factory electrical schematic for the EP20 72-80V MCIII. The same publication covers 9 further forklift models: EP16 36-48V MCIII, EP16 72-80V MCIII, EP18 36-48V MCIII, EP18 72-80V MCIII, EP20 36-48V MCIII, EP25 36-48V MCIII, EP25 72-80V MCIII, EP30 36-48V MCIII, EP30 72-80V MCIII. The cover also lists EP16 36/48V, EP16 72/80V, EP18 36/48V, EP18 72/80V, EP20 36/48V, EP20 72/80V, EP25 36/48V, EP25 72/80V, EP30 36/48V, EP30 72/80V. Check the model and serial number on your data plate before ordering.
