Clark Clarklift 60B Forklift Parts Manual (GX134B3)

A 60B Clarklift usually spends its life loading trucks, feeding docks, and shuffling pallets around warehouses and yards. This parts manual is what I keep handy when I’m tearing into one and need to be sure I’m looking at the right hardware on a GX134B3 chassis. If I’ve got a forklift with a dragging parking brake or a cracked accelerator pedal bracket, this is what I use to match what’s in front of me to the correct Clark part before I order anything.

Applications & Use Cases

• Trace the exact accelerator pedal and linkage style your truck uses so you don’t end up with the wrong pedal assembly.
• Isolate which air cleaner housing, element, and clamps belong on your machine when someone’s mixed parts over the years.
• Verify the correct alternator and belt arrangement after swapping pulleys or brackets.
• Identify the right drive and steering axle components when you’ve got oil leaks or worn kingpins during teardown.
• Cross-check parking and wheel brake parts so shoes, springs, and cables all match the GX134B3 configuration.

FAQ

Q: Can I use this on a tablet while I’m working on the truck?

A: Yes, it’s practical to keep it open on a tablet or laptop so you can zoom into the exploded views right next to the machine.

Q: Is it worth printing sections of this manual?

A: Many techs print only the relevant pages for the area they’re rebuilding and keep them in a sleeve so they don’t get ruined by grease.

Safety Note

Always verify you’ve correctly identified a part before ordering or installing it, and lock out the truck properly before any inspection or teardown.
