Clark Clarklift CY40 Forklift Parts Manual (X28A)

This CY40 Clarklift is a yard workhorse—loading trucks, shuttling pallets, and working around docks or warehouses all day. This parts manual is what I keep handy when I’m tearing into one and need to be sure I’m looking at the right bracket, valve, or linkage before I order anything. If, for example, you’ve bent a mast component or damaged a hydraulic fitting, this book lets you match what’s on the truck to the correct Clark part listing so you don’t end up with the wrong subassembly.

Applications & Use Cases

• Trace assemblies from a visible component back through its related hardware so you can see what else should be inspected or replaced together.
• Confirm part revisions when you find older or updated styles on the same model, avoiding mismatched replacements.
• Verify small hardware—clips, pins, seals—that are easy to misname over the phone when ordering.
• Cross-reference components during teardown so you can tag and bag parts and later match them to the right callouts.
• Check optional equipment layouts to identify which variant your truck actually has before ordering.

FAQ

Q: Can I use this manual on a tablet at the truck?

A: Yes, it’s practical to zoom in on the diagrams on a tablet or laptop so you can compare the drawing directly to the component on the machine.

Q: Is it worth printing sections of this manual?

A: Many techs print only the pages for the area they’re working on and keep those sheets with the parts on the bench for quick reference and notes.

Safety Note

Always lock out the truck, secure raised components, and relieve hydraulic pressure before inspecting or identifying any parts on the machine.
