Clark CMP40, CMP45, CMP50S Forklift Service Manual (SM648)

These Clark CMP40, CMP45, CMP50S forklifts spend their lives loading trucks, shuttling pallets, and working hard in warehouses and yards, often in tight spaces and rough conditions. This service manual is what I’d keep on hand whenever I need to trace a fault, tear into a major component, or put one of these trucks back together correctly. If, for example, the truck starts pulling weakly under load and you’re not sure if it’s engine, cooling, or transaxle related, this book walks you through a logical path: what to inspect first, how to test it, and how to disassemble and reassemble without guessing.

Applications & Use Cases

• Track down hard-to-find issues like intermittent no-starts or loss of drive by following step-by-step diagnostic logic.
• Plan safe teardown and reassembly of engine, cooling, and driveline components so you don’t miss fasteners, seals, or alignment steps.
• Verify adjustments on linkages, brakes, and hydraulic controls after repairs to restore proper response and feel.
• Confirm test procedures before replacing expensive parts, so you isolate the real fault instead of throwing parts at the problem.
• Support periodic service with a consistent workflow for inspections, fluid changes, and functional checks.

FAQ

Q: Can I use this manual on a tablet in the shop?

A: Yes, it’s practical to keep it on a tablet or laptop so you can zoom diagrams and search quickly while working at the truck.

Q: Is it still worth printing sections of this manual?

A: Definitely; many techs print the pages for the job they’re doing so they can make notes and keep them right beside the machine.

Safety Note

Always lock out, chock, and properly support the truck before working under or around any lifted or rotating components.

Clark CMP40, CMP45, CMP50S Forklift Index:

GROUP SA – SAFE MAINTENANCE
PERIODIC SERVICE
GROUP 00 ENGINE
GROUP 01 COOLING SYSTEM
GROUP 06 TRANSAXLE
GROUP 14 ELECTRICAL
GROUP 22 WHEELS AND TIRES
GROUP 23 BRAKES
GROUP 25/26 STEERING SYSTEM
GROUP 29/30 HYDRAULIC SYSTEM
GROUP 34 UPRIGHT
GROUP 38 COUNTERWEIGHT
GROUP 40 SPECIFICATIONS
