Clark PWD25, PWD30, PWD36, HWD25, HWD30, HWD36, P-HWP25, P-HWP30 Forklift Operators Manual (OM-568)

Clark PWD25, PWD30, PWD36, HWD25, HWD30, HWD36, P-HWP25, P-HWP30 Forklift Operators Manual (OM-568)

Format: PDF (Printable Document)

File Language: English

File Pages: 94

File Size: 10.78 MB (Speed Download Link)

Brand: Clark

Model: PWD25, PWD30, PWD36, HWD25, HWD30, HWD36, P-HWP25, P-HWP30 Forklift

Book No: OM-568

Type of Document: Operators Manual

Category: PDF

$ 40

Clark PWD25, PWD30, PWD36, HWD25, HWD30, HWD36, P-HWP25, P-HWP30 Forklift Operators Manual (OM-568)

These Clark PWD/HWD series forklifts are everyday workhorses in warehouses, loading docks, and tight yard spaces, moving pallets on and off trucks all shift long. This operator’s manual is what I keep handy to make sure the truck is started, run, and shut down the way Clark intended, so we don’t cook a drive motor or wreck a mast from bad habits. If, for example, an operator reports the truck won’t move after startup or the hydraulics feel weak, I use this book to verify the correct control positions, startup sequence, and daily checks before I start chasing a “fault” that’s really just misuse.

Applications & Use Cases

Train new operators on proper control use, travel direction changes, and safe shutdown.
Guide daily inspections of tires, forks, hydraulics, and warning devices before each shift.
Verify correct startup logic when the truck won’t move or behaves oddly after key-on.
Reinforce safe lifting practices to avoid tipping, bent masts, or damaged loads.
Standardize operating habits across different PWD/HWD models on the same site.

FAQ

Q: Can I keep this manual on a tablet or phone for use in the yard?

A: Yes, it’s well-suited for digital use, so you can zoom in on control diagrams and check procedures right at the truck.

Q: Is it worth printing parts of this manual?

A: Many shops print the daily inspection and startup pages and post them near the charging or parking area for quick reference.

Safety Note

Always follow the manual’s startup, inspection, and shutdown steps in order before lifting any load.

📘 Show Index

PWD25, PWD30, PWD36, HWD25, HWD30, HWD36, P-HWP25, P-HWP30 Forklift Index:

INTRODUCTION .
User Daily Inspection – Safety and Operating Checks.
About This Manual „
Safety Signs and Safety Messages .
A Message To Clark Lift Truck Operators
Truck Application
KNOW YOUR TRUCK
Component Location (PWD & P Models ) …
Component Location (HWD & HWP Models) ……..
Operators Controls (PWD & P Models)
Operators Controls (HWD & HWP Models) .
Maintenance Component Location (PWD & P Models).
Maintenance Component Location (HWD & HWP Modelsi.
System Description.
Nameplate Description
Warning Decals .
GENERAL SAFETY RULES.
Do’s and Don’ts .
No Riders
Pedestrians .. …..
Grades
Travel.
Pinch Points
Parkilg
OPERATING HAZARDS .
Fast Turns
Corner “Cutting”
Loose Loads
Longor Wide Loads.
Dock or Trailer Drop-Otts
Trailer Creep ,
Debris on Floor .
Floor and Elevator Capacity
Damaged Pallets and Skids.
Loading DockOPERATING PROCEDURES.
Beginning Truck Operation.
Travel Control ….. ……
High Speed Travel Control …
Emergency Reversal Switch Disengagement.
Lift and Lower Control (PWD & P Models)
Lift Lower Control (HW) & HWP Models)
Braking.
Horn Control .
Coast Control (HWD & HWD Models) .
Load Handling
Parking
DAILY INSPECTION
Daily Inspection Sheet
Operator Repairs
Emergency Reversal Switch
Travel Contror .
Horn …..
Lift and Lower Controls (PWD & P Models) ….
Lift Controls (HWD & HWP ModelS) .
Lower Controls (HWD & HWP Models) ,
Brake .
coast Control (HWD & HWP Models)
Wheels and Tires
Hydraulic System
Maintenance Problem
PLANNED MAINTENANCE AND LUBRICATION
Typical Operating Conditions …..
Daily Inspection Points
Recommended P.M. and Lubrication Schedule
User Safe Maintenance Practices
Safety Standards
Battery
Battery Handling
Battery Removal and Installation
Battery Maintenance, Records, and Life
