Clark S20, S30, S40, SP20, SP25, SP30 Forklift Planned Maintenance and Adjustment Procedures Manual (PMA321)

Clark S20, S30, S40, SP20, SP25, SP30 Forklift Index:

Powrworker I’S” Model Pictorial Index
Powrworker n SPI’ Model Pictorial Index
Lubrication Chart(s) & Specifications
Battery
Electric Battery Powered Industrial
– UL583
Trucks
Electric Drive Fbtor (Brake) Cut-off Switch
Pump Motor Operating Switch
El ectric Fbtors
El ectric Contactors
Drive Unit
Drive Wheel & Tire
Brake
Hydraulic Sump Tanks
Vertically t’bunted Tanks
Horizontally Mounted Tanks
Hydraulic Systan Pressure Checks
Single Pump Installation
Dual Pump Instal lation
Upright & Carriage ROI ler Check & Ajd.
4 & 6 Roller Carriages
Standard & Hi-Lo Upright ROI lers
Lift Chain Adjustment
Upright Down Drift and Tilt Cylinder
Bleeding Compound Lift Cyl inders . . . . . . .
Lift Chain Maintenance .
Trail (Load) Wheels
– Upright Deck
Decals
– Plates
And Serial No. Location
Truck Specifications . . . . . . . .
PM Inspection and Drivers Daily Inspection Forms
Fire Extinguisher Recomendations .
