CNH Large Rectangular Baler Service Training Manual

Out in the field, these big square balers work long hours in dust, heat, and uneven windrows, so when something goes off—missed knots, crooked flakes, driveline chatter—you need to understand the system, not just swap parts. This CNH Large Rectangular Baler Service Training Manual helps you think through how each group of components works together so you can trace a problem from the bale back to the cause. For example, if bales start varying in length, this guide helps you reason through feed, plunger timing, and knotter sequence instead of guessing.

Applications & Use Cases

• Build system understanding so new techs learn how the hitch, driveline, and bale-forming systems interact under load.
• Improve diagnostic flow when chasing intermittent twine issues, feeding jams, or out-of-time plungers.
• Verify adjustments after repairs, making sure timing, clearances, and motion sequences make sense before you spin it up.
• Support preventive maintenance by explaining why certain inspections and lubrication points matter.
• Train seasonal staff so they can recognize early signs of failure and report useful symptoms.

FAQ

Q: Can I use this on a tablet in the field?

A: Yes, it’s well-suited to digital use; you can zoom diagrams and search terms while you’re standing by the baler.

Q: Is it still worth printing parts of it?

A: Many techs print the key theory and diagnostic pages to keep in a shop binder for quick reference during busy season.

Safety Note

Always lock out power, secure all stored energy, and keep guards in place before inspecting or testing any moving baler components.

CNH Large Rectangular Baler Index:

Introduction
2 General Information
3 Hitch & Driveline
4 Pick-up
5 Feeding
6 Stuffer
7 Plunger
8 Knotters
9 Bale Ejection
10 Electrical /Electronics
11 Hydraulics
12 Lubrication
13 Frame & Axles
14 Accessories & DIA Kits
