CNH REAR CAMERA KIT Installation Instructions (92710356)

Format: PDF (Printable Document)

File Language: English

File Pages: 140

File Size: 16.16 MB (Speed Download Link)

Brand: CNH

Model: REAR CAMERA KIT

Book No: 92710356

Type of Document: Installation Instructions

Categories: ,

$ 45

Share:

CNH REAR CAMERA KIT Installation Instructions (92710356)

CNH REAR CAMERA KIT Installation Instructions (92710356)

Machines running a rear camera kit like this are usually in tight yards, muddy sites, and busy loading areas where you’re backing near trucks, piles, and people. This manual walks you through how to mount, route, and hook up the CNH rear camera kit so it actually works when you drop it in reverse. Say you’ve just bought a used loader with no camera: this guide helps you trace the harness, align the brackets, and verify the monitor powers up without guessing or tearing the cab apart twice.

Applications & Use Cases

  • Install a new rear camera on a machine that never had one by following the bracket locations, routing paths, and connection points the way CNH intended.
  • Replace a damaged camera or harness and test the system step-by-step so you can isolate whether the fault’s in the camera, wiring, or display.
  • Clean up a bad previous install by re-routing cables correctly, securing them away from pinch points, and checking connectors so they don’t chafe or pull loose.
  • Add the kit before a busy season, then inspect and verify image quality and viewing angle so operators can actually see what’s behind them.
  • Troubleshoot flicker or no image using the manual’s checks to trace power, confirm ground, and test signal without just throwing parts at it.

FAQ

Q: Is this a PDF I can search on my laptop or phone?

A: It’s typically a PDF; you can usually search text, zoom wiring views, and keep it handy in the cab or shop.

Q: Can I print just the pages I need to take to the machine?

A: Yes, most folks print the wiring and mounting pages so they can mark them up, then keep the full file saved for later.

Safety Note

Always lock out the machine, chock the wheels, and keep the key with you before you start routing or inspecting any rear camera wiring.

CNH REAR CAMERA KIT Index:

SAFETY

KIT CONTENT

PRE-ASSEMBLY

ASSEMBLY

CNH

92710358 – REAR CAMERA KIT
CASE CONSTRUCTION
221G STANDARD SPEED, TIER 4B
221G STANDARD SPEED, TIER 4B
221G STANDARD SPEED, STAGE V
221G HIGH SPEED, TIER 4B
221G HIGH SPEED, TIER 4B
221G HIGH SPEED, STAGE V
321G STANDARD SPEED, TIER 4B
321G STANDARD SPEED, TIER 4B
321G STANDARD SPEED, STAGE V
321G HIGH SPEED, TIER 4B
321G HIGH SPEED, TIER 4B
321G HIGH SPEED, STAGE V
321G XR STANDARD SPEED, TIER 4B
321G XR STANDARD SPEED, TIER 4B
321G XR STANDARD SPEED, STAGE V
321G XR HIGH SPEED, TIER 4B
321G XR HIGH SPEED, TIER 4B
321G XR HIGH SPEED, STAGE V
NEW HOLLAND CONSTRUCTION
W70D STANDARD SPEED, TIER 4B
W70D STANDARD SPEED, STAGE V
W70D HIGH SPEED, TIER 4B
W70D HIGH SPEED, STAGE V
W80D STANDARD SPEED, STAGE V
W80D HIGH SPEED, TIER 4B
W80D HIGH SPEED, STAGE V
W80D LR STANDARD SPEED, STAGE V
W80D LR HIGH SPEED, TIER 4B
W80D LR HIGH SPEED, STAGE V
Lec
