Description

Doosan DL08C Engine Wheel Loader Operation and Maintenance Manual

Doosan DL08C Engine Wheel Loader Index:

1. Safety Regulations & Specifications …………………………………………………………………………… 1
1.1. Safety Regulations 1.4. Engine Performance Curve
1.2. Engine Specifications 1.5. Engine Assembly
1.3. Engine Power
2. Technical Information ………………………………………………………………………………………………. 11
2.1. Engine Model and Serial Number 2.4. Diagnosis and Remedy
2.2. Diagnostic Tool (SCAN-200) 2.5. Engine Inspection
2.3. Engine Character
3. Disassembly and Reassembly of Major Components ……………………………………………….. 43
3.1. Engine Disassembly 3.5. Electrical System
3.2. Inspection and Measurement on Major Parts 3.6. Engine Diagnostic
3.3. Reassembly 3.7. Operating Condition of the ECU
3.4. Fuel Injection System
4. Commissioning and Operation ………………………………………………………………………………. 130
4.1. Preparations 4.6. Maintenance and Care
4.2. Breaking-In 4.7. Cooling System
4.3. Inspections after Starting 4.8. Adjustment of Valve Clearance
4.4. Operation in Winter Time 4.9. Tightening the Cylinder Head Bolts
4.5. Engine Components Check after Long Time Running
5. Maintenance of Major Components ………………………………………………………………………… 144
5.1. Cooling System 5.3. Turbo Charger
5.2. Lubrication System 5.4. Belt
6. Special Tool List ……………………………………………………………………………………………………. 162
• Appendix
• Parts & After service center
• Applications for DOOSAN’s Engine
