Description
Doosan DX225MH-5 Material Handler Shop Manual (Serial Number 1001 and Up)
Doosan DX225MH-5 Material Handler Index:
1 Safety 1 Track Material Handler Maintenance
Safety
2 Specifications 1 Specifications
3 General Maintenance 1 General Maintenance Instructions
2 Standard Torques
4 Engine 1 Engine
2 Engine Coolant Heater (Option)
5 Upper Structure 1 Cabin
2 Counterweight
3 Hydraulic Oil Tank
4 Fuel Tank
5 Main Pump
6 Drive Coupling (Main Pump)
7 Main Control Valve
8 Swing Device
9 Joystick Valve (Work Lever)
10 Dozer Joystick Valve
11 Travel Control Valve (with Damper)
12 Solenoid Valve
13 EPPR Valve (One or Two-way)
14 Accumulator
15 Gear Pump (Rotating)
16 One Spool Valve (Rotating)
6 Lower Structure and Chassis 1 Swing Bearing
2 Center Joint
3 Center Joint (Dozer)
4 Travel Device
5 Track Assembly
6 Dozer System
7 Front 1 Boom and Arm
2 Attachment
3 Cylinders
8 Hydraulic System 1 Hydraulic System
2 Hydraulic System Testing and Adjustment
3 Hydraulic System Troubleshooting
9 Electrical System 1 Electrical System
10 Options 1 One Way
2 Two-way
3 Rotating
4 Two Pump
11 Schematic 1 Hydraulic Schematic/Electrical Schematic
