Format: PDF (Printable Document)
Language: EN
File Size: 8.56 MB (Speed Download Link)
Pages: 101
Brand: Hitachi
Type of Document: Service Manual
Type of Machine: KH125-3 Earth Drill
KM302E-00ED
Original price was: $ 45.$ 40Current price is: $ 40.
KH125-3 Earth Drill Index:
SECTION 01 SPECIFICATION
SECTION 02 CONSTRUCTION
SECTION 03 HYDRAULIC SYSTEM
SECTION 04 ELECTRIC SYSTEM
SECTION 05 MAINTENANCE
SECTION 06 PRECAUTIONS FOR EARTH DRILL OPERATION
SECTION 07 FRONT ATTACHMENT ASSEMBLY
FRONT FRAME
(BASE MACHINE)
PIPING;MOTOR (FRONT)
(FRONT)
PIPING;CYLINDER (BASE MACHINE)
CONTROL DEVICE (BASE MACHINE)
CONTROL DEVICE (BASE MACHINE)
VALVE COVER (BASE MACHINE)
HOLDING ROPE DEVICE
ROPE GUIDE
KELLY DRIVE DEVICE
SWIVEL JOINT
MAIN HOIST DRUM (22mm)
KELLY BAR 16.6m
HOOK OVERHOIST DEVICE
