Hyster H70-120XM (K005 C813) Forklift Service Manual

Format: PDF (Printable Document)

File Language: English

File Pages (Total): 2414

File Size (Total): 82.22 MB (Speed Download Link)

Brand: Hyster

Model: H70-120XM (K005 C813) Forklift

Type of Document: Service Manual

Categories: ,

$ 45

Share:

Hyster H70-120XM (K005 C813) Forklift Service Manual

Hyster H70-120XM (K005 C813) Forklift Service Manual

📘 Show Index

Hyster H70-120XM (K005 C813) Forklift Index:

  • General
    • General Safety Rules
  • Description
    • Engine Serial Number Codes
    • Engine Data
  • Engine Removal and Installation
    • Lift Engine
  • Cylinder Head Assembly Repair
    • Valve Cover
      • Remove
      • Install
    • Rocker Arm Assembly
      • Remove
      • Install
      • Disassemble
      • Inspect
      • Assemble
    • Valve Clearance Adjustments
      • Four-Cylinder Engines
      • Six-Cylinder Engines
    • Valve Springs
    • Cylinder Head Assembly
      • Remove
      • Install
    • Valves and Valve Springs
      • Remove
      • Inspect
      • Install
    • Valve Guides
      • Inspect
      • Remove
      • Install
    • Cylinder Head and Valve Seats
      • Inspect
      • Repair
      • New Valve Seats, Install
  • Piston and Connecting Rod Assemblies Repair
    • Rod Bearings
      • Remove
      • Install
    • Piston and Connecting Rod Assembly
      • Service Note
      • Remove
      • Install
    • Piston Rings
      • Remove
      • Inspect
      • Install
    • Piston and Connecting Rod
      • Disassemble
      • Inspect
      • How to Select Correct Replacements
      • Install
    • Piston Cooling Jets
      • Remove
      • Install
  • Crankshaft Assembly Repair
    • General
    • Crankshaft Pulley
      • Engine AR, Remove
      • Engines YG and YH, Remove
      • Inspect
      • Engine AR, Install
      • Engines YG and YH, Install
    • Rear Oil Seal
      • Replace
    • Main Bearings
      • Remove
      • Inspect
      • Install
    • Thrust Washers
      • Crankshaft Axial Movement, Check
      • Remove
      • Install
    • Crankshaft
      • Remove
      • Inspect
      • Install
    • Flywheel
      • Remove
      • Ring Gear, Replace
      • Install
    • Flywheel Housing
      • Remove
      • Install
  • Timing Case and Timing Gears Repair
    • General
    • Timing Case Cover
      • Remove
      • Install
    • Front Oil Seal
      • Remove
      • Install
    • Crankshaft Pulley Wear Sleeve
      • Install
    • Idler Gear and Hub
      • Remove
      • Install
    • Air Compressor Drive, Bendix
      • Disassemble
      • Assemble
    • Fuel Injection Pump Gear
      • Remove
      • Install
    • Camshaft Gear
      • Remove
      • Install
    • Crankshaft Gear
      • Remove
      • Install
    • Timing Case
      • Remove
      • Install
    • Camshaft and Tappets
      • Remove
      • Install
  • Cylinder Block Assembly Repair
    • Description
    • Cylinder Block
      • Disassemble
      • Inspect
      • Assemble
    • Cylinder Bore (Four-Cylinder Engines)
    • Cylinder Liner (Six-Cylinder Engines)
      • Inspect
      • Cylinder Liner Condition, Check
      • Remove
      • Service Liner, Install
      • Partially Finished Liner, Install
  • Engine Timing
    • Description
      • How to Set Number One Piston to TDC on Compression Stroke
      • How to Set Number One Piston to TDC on Compression Stroke (Alternate Procedure)
      • Valve Timing, Check
      • Fuel Injection Pump Timing, Check
  • Turbocharger – Engine YH Repair
    • General
      • Remove
      • Install
      • Impeller and Compressor Housing, Clean
  • Lubrication System Repair
    • General
    • Oil Filter, Replace
    • Filter Head
      • Remove and Install
    • Oil Sump
      • Remove
      • Install
    • Oil Pump
      • Remove
      • Inspect
      • Install
    • Relief Valve
      • Remove
      • Disassemble
      • Inspect
      • Assemble
      • Install
    • Idler Gear Shaft, Replace
      • Remove
      • Remove (Alternative)
      • Install
      • Install (Alternative)
      • Install (Alternative for Four-Cylinder Engines Only)
  • Fuel System Repair
    • Description
    • Fuel Injection Pump
      • Remove
      • Install
      • Check and Adjust
    • Fuel System Air Removal
    • Fuel Filter, Replace
      • Canister Type
      • Quick Release Canister Type
    • Fuel Injectors
      • Remove
      • Inspect
      • Install
    • Fuel Pump
      • Remove
      • Disassemble
      • Assemble
      • Install
      • Test
  • Cooling System Repair
    • General
    • Thermostat
      • Remove
      • Install
      • Test
    • Coolant Pump
      • Remove
      • Disassemble
      • Assemble
      • Install
    • Fan and Fan Drive
      • Remove
      • Install
    • Oil Cooler (Six-Cylinder Engines)
      • Remove
      • Disassemble and Assemble
      • Install
      • Oil Cooler Bypass Valve
  • Electrical Equipment Repair
    • Drive Belts
      • Adjustment
      • Remove
      • Install
    • Alternator
      • Remove
      • Install
    • Starter Motor
      • Remove
      • Install
    • Cold Start Aid
  • Air Compressor – Engines YG and YH
    • General
    • Repair
      • Remove
      • Install
  • Rotary Exhauster Replacement
    • Remove
    • Clean
    • Install
  • Engine Specifications
    • Cylinder Head Assembly
    • Piston and Connecting Rods
    • Crankshaft Assembly
      • Crankshaft Overhaul
    • Timing Case and Drive Assembly
    • Engine Block Assembly
    • Turbocharger
    • Lubrication System
    • Fuel System
    • Cooling System
    • Flywheel and Housing
    • Electrical Equipment
  • Torque Specifications
    • Cylinder Head Assembly
    • Piston and Connecting Rod Assemblies
    • Crankshaft Assembly
    • Timing Case and Drive Assembly
    • Turbocharger
    • Lubrication System
    • Fuel System
    • Cooling System
    • Flywheel
    • Auxiliary Equipment
  • Special Torque Specifications
    • Flywheel and Housing
    • Turbocharger
    • Electrical Equipment
    • Auxiliary Equipment
  • Special Tools*
  • Troubleshooting
  • General
    • General Safety Rules
  • Description
    • Engine Serial Number Codes
    • Engine Data
  • Engine Removal and Installation
    • Lift Engine
  • Cylinder Head Assembly Repair
    • Valve Cover
      • Remove
      • Install
    • Rocker Arm Assembly
      • Remove
      • Install
      • Disassemble
      • Inspect
      • Assemble
    • Valve Clearance Adjustments
      • Four-Cylinder Engines
      • Six-Cylinder Engines
    • Valve Springs
    • Cylinder Head Assembly
      • Remove
      • Install
    • Valves and Valve Springs
      • Remove
      • Inspect
      • Install
    • Valve Guides
      • Inspect
      • Remove
      • Install
    • Cylinder Head and Valve Seats
      • Inspect
      • Repair
      • New Valve Seats, Install
  • Piston and Connecting Rod Assemblies Repair
    • Rod Bearings
      • Remove
      • Install
    • Piston and Connecting Rod Assembly
      • Service Note
      • Remove
      • Install
    • Piston Rings
      • Remove
      • Inspect
      • Install
    • Piston and Connecting Rod
      • Disassemble
      • Inspect
      • How to Select Correct Replacements
      • Install
    • Piston Cooling Jets
      • Remove
      • Install
  • Crankshaft Assembly Repair
    • General
    • Crankshaft Pulley
      • Engine AR, Remove
      • Engines YG and YH, Remove
      • Inspect
      • Engine AR, Install
      • Engines YG and YH, Install
    • Rear Oil Seal
      • Replace
    • Main Bearings
      • Remove
      • Inspect
      • Install
    • Thrust Washers
      • Crankshaft Axial Movement, Check
      • Remove
      • Install
    • Crankshaft
      • Remove
      • Inspect
      • Install
    • Flywheel
      • Remove
      • Ring Gear, Replace
      • Install
    • Flywheel Housing
      • Remove
      • Install
  • Timing Case and Timing Gears Repair
    • General
    • Timing Case Cover
      • Remove
      • Install
    • Front Oil Seal
      • Remove
      • Install
    • Crankshaft Pulley Wear Sleeve
      • Install
    • Idler Gear and Hub
      • Remove
      • Install
    • Air Compressor Drive, Bendix
      • Disassemble
      • Assemble
    • Fuel Injection Pump Gear
      • Remove
      • Install
    • Camshaft Gear
      • Remove
      • Install
    • Crankshaft Gear
      • Remove
      • Install
    • Timing Case
      • Remove
      • Install
    • Camshaft and Tappets
      • Remove
      • Install
  • Cylinder Block Assembly Repair
    • Description
    • Cylinder Block
      • Disassemble
      • Inspect
      • Assemble
    • Cylinder Bore (Four-Cylinder Engines)
    • Cylinder Liner (Six-Cylinder Engines)
      • Inspect
      • Cylinder Liner Condition, Check
      • Remove
      • Service Liner, Install
      • Partially Finished Liner, Install
  • Engine Timing
    • Description
      • How to Set Number One Piston to TDC on Compression Stroke
      • How to Set Number One Piston to TDC on Compression Stroke (Alternate Procedure)
      • Valve Timing, Check
      • Fuel Injection Pump Timing, Check
  • Turbocharger – Engine YH Repair
    • General
      • Remove
      • Install
      • Impeller and Compressor Housing, Clean
  • Lubrication System Repair
    • General
    • Oil Filter, Replace
    • Filter Head
      • Remove and Install
    • Oil Sump
      • Remove
      • Install
    • Oil Pump
      • Remove
      • Inspect
      • Install
    • Relief Valve
      • Remove
      • Disassemble
      • Inspect
      • Assemble
      • Install
    • Idler Gear Shaft, Replace
      • Remove
      • Remove (Alternative)
      • Install
      • Install (Alternative)
      • Install (Alternative for Four-Cylinder Engines Only)
  • Fuel System Repair
    • Description
    • Fuel Injection Pump
      • Remove
      • Install
      • Check and Adjust
    • Fuel System Air Removal
    • Fuel Filter, Replace
      • Canister Type
      • Quick Release Canister Type
    • Fuel Injectors
      • Remove
      • Inspect
      • Install
    • Fuel Pump
      • Remove
      • Disassemble
      • Assemble
      • Install
      • Test
  • Cooling System Repair
    • General
    • Thermostat
      • Remove
      • Install
      • Test
    • Coolant Pump
      • Remove
      • Disassemble
      • Assemble
      • Install
    • Fan and Fan Drive
      • Remove
      • Install
    • Oil Cooler (Six-Cylinder Engines)
      • Remove
      • Disassemble and Assemble
      • Install
      • Oil Cooler Bypass Valve
  • Electrical Equipment Repair
    • Drive Belts
      • Adjustment
      • Remove
      • Install
    • Alternator
      • Remove
      • Install
    • Starter Motor
      • Remove
      • Install
    • Cold Start Aid
  • Air Compressor – Engines YG and YH
    • General
    • Repair
      • Remove
      • Install
  • Rotary Exhauster Replacement
    • Remove
    • Clean
    • Install
  • Engine Specifications
    • Cylinder Head Assembly
    • Piston and Connecting Rods
    • Crankshaft Assembly
      • Crankshaft Overhaul
    • Timing Case and Drive Assembly
    • Engine Block Assembly
    • Turbocharger
    • Lubrication System
    • Fuel System
    • Cooling System
    • Flywheel and Housing
    • Electrical Equipment
  • Torque Specifications
    • Cylinder Head Assembly
    • Piston and Connecting Rod Assemblies
    • Crankshaft Assembly
    • Timing Case and Drive Assembly
    • Turbocharger
    • Lubrication System
    • Fuel System
    • Cooling System
    • Flywheel
    • Auxiliary Equipment
  • Special Torque Specifications
    • Flywheel and Housing
    • Turbocharger
    • Electrical Equipment
    • Auxiliary Equipment
  • Special Tools*
  • Troubleshooting
  • toc
    • Electronic Engine Control
    • Safety Precautions Maintenance and Repair
    • General
      • Engine Data
    • Light Bulb Check
    • System Check
    • Troubleshooting With Fault Monitor System in ECM
      • How to Clear a Code
      • Fault In the ECM
      • Fuel Control
      • Idle Air Control (IAC)
      • Fuel Pump Circuit
      • Coolant Temperature Sensor (CTS)
      • Manifold Absolute Pressure Sensor (MAP)
      • Throttle Position Sensor (TPS)
      • Throttle Position Sensor Output Check
      • Electronic Spark Timing (EST)
      • Distributor Reference Signal
    • A-1 – No Service Engine Soon Light
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks:
    • A-2 – No Diagnostic Data or Code 12
      • Circuit Description
      • Test Description
    • A-3 – Starter Cranks Engine, But Does Not Run
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks:
    • A-4 – Fuel Injector Circuit
      • Circuit Description
      • Test Description
    • A-5 – Fuel Pump Relay Circuit
      • Circuit Description
      • Test Description
    • A-6 – Fuel System Pressure Test
      • Circuit Description
      • Test Description
    • A-7 – MAP Output Check
      • Circuit Description
      • Test Description
    • A-8 – Ignition System Troubleshooting
      • Circuit Description
      • Test Description
    • A-9 – Idle Air Control (IAC) System
      • Circuit Description
      • Test Description
    • Fault Code 14 – Coolant Temperature Sensor Circuit (Indicates Lo
      • Circuit Description
      • Test Description
    • Fault Code 15 – Coolant Temperature Sensor Circuit (Indicates Hi
      • Circuit Description
      • Test Description
    • Fault Code 21 – Throttle Position Sensor Circuit (Signal Voltage
      • Circuit Description
      • Test Description
    • Fault Code 22 – Throttle Position Sensor Circuit (Signal Voltage
      • Circuit Description
      • Test Description
    • Fault Code 31 – Engine Governor Circuit
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 33 – MAP Sensor Circuit, Signal Voltage High (Low Vac
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 34 – MAP Sensor Circuit, Signal Voltage Low (High Vac
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 41 – Electronic Spark Timing (EST), Open Circuit
      • Circuit Description
      • Test Description
    • Fault Code 42 – EST, Grounded IC Circuit, Open or Grounded Bypas
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 51 – ECM Failure
      • Circuit Description
      • Other Troubleshooting Checks
    • Troubleshooting, Poor Operation
      • General
    • Fuel System Components Repair
      • General
      • Fuel Control
      • Injection Throttle Body (ITB) Assembly
      • Governor Throttle Body (GTB) Assembly
    • Electrical Components Repair
      • General
      • Ignition Coil Test
      • Ignition Module Test
      • Distributor
      • Ignition Timing
      • Ignition Coil
      • Coolant Temperature Sensor (CTS) Replacement
      • Manifold Absolute Pressure (MAP) Sensor Replacement
      • Oil Pressure Sender Replacement
      • Low Coolant Sender Replacement
      • Wire Harness
      • Connectors and Terminals
      • Electronic Control Module (ECM)
    • Special Tools
  • tables
    • Table 1. ECM Diagnostic Codes
    • Table 2. Wire Harness Repair
    • Table 3. Weather-Pack Terminal Repair
    • Table 4. ECM Connector J1 Identification
    • Table 5. ECM Connector J2 Identification
  • toc
    • Electronic Engine Control
    • Safety Precautions Maintenance and Repair
    • General
      • Engine Data
    • Light Bulb Check
    • System Check
    • Troubleshooting With Fault Monitor System in ECM
      • How to Clear a Code
      • Fault In the ECM
      • Fuel Control
      • Idle Air Control (IAC)
      • Fuel Pump Circuit
      • Coolant Temperature Sensor (CTS)
      • Manifold Absolute Pressure Sensor (MAP)
      • Throttle Position Sensor (TPS)
      • Throttle Position Sensor Output Check
      • Electronic Spark Timing (EST)
      • Distributor Reference Signal
    • A-1 – No Service Engine Soon Light
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks:
    • A-2 – No Diagnostic Data or Code 12
      • Circuit Description
      • Test Description
    • A-3 – Starter Cranks Engine, But Does Not Run
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks:
    • A-4 – Fuel Injector Circuit
      • Circuit Description
      • Test Description
    • A-5 – Fuel Pump Relay Circuit
      • Circuit Description
      • Test Description
    • A-6 – Fuel System Pressure Test
      • Circuit Description
      • Test Description
    • A-7 – MAP Output Check
      • Circuit Description
      • Test Description
    • A-8 – Ignition System Troubleshooting
      • Circuit Description
      • Test Description
    • A-9 – Idle Air Control (IAC) System
      • Circuit Description
      • Test Description
    • Fault Code 14 – Coolant Temperature Sensor Circuit (Indicates Lo
      • Circuit Description
      • Test Description
    • Fault Code 15 – Coolant Temperature Sensor Circuit (Indicates Hi
      • Circuit Description
      • Test Description
    • Fault Code 21 – Throttle Position Sensor Circuit (Signal Voltage
      • Circuit Description
      • Test Description
    • Fault Code 22 – Throttle Position Sensor Circuit (Signal Voltage
      • Circuit Description
      • Test Description
    • Fault Code 31 – Engine Governor Circuit
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 33 – MAP Sensor Circuit, Signal Voltage High (Low Vac
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 34 – MAP Sensor Circuit, Signal Voltage Low (High Vac
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 41 – Electronic Spark Timing (EST), Open Circuit
      • Circuit Description
      • Test Description
    • Fault Code 42 – EST, Grounded IC Circuit, Open or Grounded Bypas
      • Circuit Description
      • Test Description
      • Other Troubleshooting Checks
    • Fault Code 51 – ECM Failure
      • Circuit Description
      • Other Troubleshooting Checks
    • Troubleshooting, Poor Operation
      • General
    • Fuel System Components Repair
      • General
      • Fuel Control
      • Injection Throttle Body (ITB) Assembly
      • Governor Throttle Body (GTB) Assembly
    • Electrical Components Repair
      • General
      • Ignition Coil Test
      • Ignition Module Test
      • Distributor
      • Ignition Timing
      • Ignition Coil
      • Coolant Temperature Sensor (CTS) Replacement
      • Manifold Absolute Pressure (MAP) Sensor Replacement
      • Oil Pressure Sender Replacement
      • Low Coolant Sender Replacement
      • Wire Harness
      • Connectors and Terminals
      • Electronic Control Module (ECM)
    • Special Tools
  • tables
    • Table 1. ECM Diagnostic Codes
    • Table 2. Wire Harness Repair
    • Table 3. Weather-Pack Terminal Repair
    • Table 4. ECM Connector J1 Identification
    • Table 5. ECM Connector J2 Identification
  • toc
    • Periodic Maintenance
    • Safety Precautions Maintenance and Repair
    • General
      • Serial Number Data
      • How to Move Disabled Lift Truck
      • How to Put Lift Truck on Blocks
    • Maintenance Schedule
    • Maintenance Procedures Every 8 Hours or Daily
      • How to Make Checks With Engine Stopped
      • How to Make Checks With Engine Running
    • Maintenance Procedures Every 250 Hours or 6 Weeks
      • Engine Oil and Filter, GM V-6 EPA Compliant Engine (Americas Onl
      • Air Filter, GM V-6 EPA Compliant Engine
    • Maintenance Procedures Every 500 Hours or 2 Months
      • Lift Chains Lubrication
      • Air Filter
      • Hydraulic Pump Drive Shaft
      • Engine Oil and Filter, Diesel and GM V-6 (European Only)
      • Drive Belts
      • Perkins Diesel Engine
      • GM 4.3L Engine
      • Hydraulic Tank Breather, Clean and Check
      • Hydrostatic Transmission Filter
      • Brake Fluid
      • Lift Chains Wear Check
      • Forks, Wear and Damage Check
      • Mast, Lubrication
      • Control Levers and Pedals, Lubrication
      • Steering Axle, Lubrication
      • Fuel System, Checks and Adjustments
      • Cooling System, Clean Debris from Radiator Core
    • Maintenance Procedures Every 1000 Hours or 6 Months
      • PCV Valve, GM V-6
      • Crankcase Breather, GM-V6
      • Spark Plug Replacement
      • Valve Clearance, Check and Adjust
      • Water Separator, Diesel Engine
      • Fuel Filter, Replace (Diesel Engine)
      • Fuel System Air Removal, Perkins (1004.42 Diesel Engine)
      • Cooling System, GM V-6 EPA Compliant Engine
      • LPG Fuel Filter GM V-6 EPA Compliant Engine, Replace
      • Inspect Engine Electrical System, Connectors, and FCVS Connectio
    • Maintenance Procedures Every 2000 Hours or Yearly
      • Differential Thrust Screw
      • Hydraulic System
      • Powershift Transmission Oil and Filter, Replace
      • Hydrostatic Transmission Oil and Filter, Replace
      • Cooling System
      • Wheel Bearings
      • PCV Valve, GM V-6
      • Service Brakes
      • Brake Booster Filter, Replace
      • LPG Filter, Replace (Pre-2004)
      • Gasoline Fuel Filter, Replace
      • Operator Restraint System
      • Oxygen Sensor (Pre 2004)
      • Oxygen Sensor GM V-6 EPA Compliant Engine
      • Air Filter Element, GM V-6 EPA Compliant Engine
      • Inspect Low Pressure Regulator (LPR) for Oil Buildup and Leaks
      • Check Throttle Shaft for Sticking
      • Inspect Exhaust Manifold and Piping for Leaks
      • Test LPG/GAS Regulator Pressure
    • Safety Procedures When Working Near Mast
    • Lift Chain Adjustments
    • Fuel Injectors Repair
    • Lift and Tilt System Leak Check
      • Lift Cylinders, Leak Check
      • Tilt Cylinders, Leak Check
    • Welding Repairs
    • Overhead Guard Changes
    • Wheel and Tire Replacement
      • Remove Wheels From Lift Truck
      • Remove Wheel From Tire
      • Install Wheel in Tire
      • Add Air to Tires
      • Wheels, Install
    • Dual Drive Wheels Installation
    • Solid Rubber Tire Repair
      • Wheel, Tire Remove
      • Wheel, Tire Install
      • SIT Tire, Change for H3.50-5.50XM (European Trucks Only)
    • Adhesives and Sealants
    • Hydraulic Oil, Lubricant, and Coolant Specifications
  • tables
    • Table 1. Maintenance Schedule
    • Table 2. Hook-Type Carriage Chain Adjustment
    • Table 3. Pin-Type Carriage Chain Adjustment

Hyster

Latest Product

0
    0
    Your Cart
    Your cart is emptyReturn to Shop
