Description

John Deere 5300N, 5400N and 5500N Tractors Technical Manual (TM4598)

John Deere 5300N, 5400N and 5500N Tractors INDEX:

SECTION CS—SAFETY
Group 05—Safety
SECTION IO—GENERAL SPECIFICATIONS
Group 05—Machine Specifications
Group IO—Fuel, Lubricants and Coolant
Group 15—Serial Number Locations
SECTION 20—ENGlNE — REPAIR
Group 00—RemovaI and Installation Of Engine
Components
SECTION 30—FUEL AND AIR INTAKE SYSTEMS
— REPAIR
Group 05—Fuel System
Group IO—Speed Control Linkage
Group 15—Air Intake System
SECTION 40—ELECTRlCAL SYSTEM — REPAIR
Group 05—Battery, Starting Motor and Alternator
Group IO—Switches and Sending Units
Group 15—Wiring Harnesses
SECTION 50—POWER TRAIN — REPAIR
Group 00—Removal and Installation of Power
Train Components
Group 05—Clutch
Group IO—Hi-Lo System (24/24-Speed
Transmission)
Group 15—Power Take-Off
Group 20—Differential
Group 25—Final Drives
Group 30—Mechanical Front Wheel Drive
Group 35—MFWD Clutch – 12/12-Speed
Transmission
Group 40—MFWD Clutch – 24/24-Speed
Transmission
Group 45—Transmission
SECTION GO—STEERING AND BRAKE SYSTEMS
_ REpAlR
Group 05—Steering System
Group IO—Brake System
SECTION 70—HYDRAULlC SYSTEM — REPAIR
Group 05—HydrauIic Pump and Filter
Group IO—Rockshaft
Group 15—Selective Control Valves
SECTION 80—MlSCELLANEOUS — REPAIR
Group 05—Front Axle (without MFWD)
Group IO—Front Wheel Bearings
Group 15—Three-Point Hitch
SECTION 90—OPERATOR’S STATION — REPAIR
Group 05—0perator’s Seat and Support
Group IO—Roll-Gard
Group 15—Fenders
Group 20—-Cab Components
Group 25—Air Conditioning System
SECTION 240—ELECTRlCAL SYSTEM —
OPERATION AND TESTS
Group 05—-Component Location
Group IO—Theory Of Operation
Group 15—Diagnosis, Tests and Adjustments
Group 20—Wiring Diagrams
SECTION 250—POWER TRAIN — OPERATION
AND TESTS
Group 05—Component Location
Group IO—Theory of Operation
Group 15—Diagnosis, Tests and Adjustments
SECTION 260—STEERlNG AND BRAKE
SYSTEMS — OPERATION AND
TESTS
Group 05—Component Location
Group IO—Theory of Operation
Group 15—Diagnosis, Tests and Adjustments
SECTION 270—HYDRAULlC SYSTEM —
OPERATION AND TESTS
Group 05—-Component Location
Group IO—Theory of Operation
Group 15—Diagnosis
Group 20—Tests

Group 25—Adjustments
Group 30—HydrauIic System Schematic
SECTION 290—0PERATOR’S STATION
Group 05—Air Conditioning System Components
Group 05—Air Conditioning System – Theory of
Operation
SECTION 299—SPEClAL TOOLS —
SELF-MANUFACTURED
Group 05—Manufacturing the Tools
