John Deere 570 575 and 375 Skid Steer Loaders Technical Manual (TM1359)
John Deere 570 575 and 375 Skid Steer Loaders INDEX:
SECTION IO—GENERAL INFORMATION
Group 05—1ntroduction and Safety
Group IO—General Specifications
Group 15—Cap Screw Torque
Group 20—Tune-lJp
Group 25—Fuel and Lubrication—570
Group 30—Fuel and Lubrication—575 and 375
Group 35—Serial Numbers
SECTION 20—DlESEL ENGINE
Group 05—Engine Removal and
Installation—Model 575
Group 06—Engine Removal and Installation
Model 375
Group IO—Cooling System
SECTION 25—GASOLINE ENGINE
Group 05—Gasoline Engine Removal and
Installation
Group IO—Valve Actuating Means and Camshaft
Group 15—Manif01d, Cylinder Heads and Valves
Group 20—FlywheeI and Housing
Group 25—Connecting Rods and Pistons
Group 30—Crankshaft and Main Bearings
Group 35—Gear Housing
Group 40—Lubrication System
Group 45—CooIing System
SECTION 30—FUEL AND AIR SYSTEM—DIESEL
Group 05—Throttle Control Linkage
Group IO—External Fuel Supply
SECTION 35—FUEL AND AIR SYSTEM
(GASOLINE)
Group 05—Carburetor
Group IO—Carburetor and Governor Linkages
Group 15—Extemal Fuel Supply
SECTION 40—ELECTRlCAL
Group 570
Group 570
Group 15—Seat Lockout Switch
Index
SECTION so—POWER TRAIN
Group 05—Hydrostatic Pumps—Models 570 and
575
Group 06—Hydrostatic Pump—Model 375
Group IO—Hydrostatic Motors—Models 570 and
575
Group II—Hydrostatic Motors—Model 375
Group 15—Drive Chains and Axles—Models 570
and 575
Group 16—Drive Chains and Axles—Model 375
Group 20—Drive Shaft
SECTION 60—STEERlNG AND BRAKES
Group 05—Park Brake
Group IO—Steering Neutralizer
SECTION 70—HYDRAULICS
Group 05—Hydraulic Pump—Models 570 and 575
Group 06—Hydraulic Pump—Model 375
Group IO—Main Control Valve
Group 15—Hydraulic Cylinders
Group 20—Miscellaneous Hydraulics
Group 25—Lift Arms, Linkage and Stops
SECTION 210—SPEClFlCATIONSIOPERATlONAL
CHECKOUT
Group 01—Test and Adjustment Specifications
Group 05—Machine Operational Checkout
SECTION 220—ENGlNE OPERATION AND TESTS
croup 05—Engine system Checkout—375/575
Group 06—Engine System Checkout—570
Group IO—Engine System Diagnosis—375/575
Group II—Engine System Diagnosis—570
SECTION 240—ELECTRlCAL OPERATION AND
TESTS
Group 05—Electrical System Checkout
Group IO—EIectrical System Diagnosis
Group 15—-Component Locations and Diagrams
SECTION 250—POWER TRAIN OPERATION AND
TESTS
Group 05—Power Train System Checkout
Group IO—Power Train Tests and Adjustments
SECTION 270—HYDRAULlC OPERATION AND
TEST
Group 05—Hydraulic System Checkout
Group IO—HydrauIic System Tests
Group 15—Schematic Diagrams
