Kohler 35-175REOZT4 Mobile Generator Sets Wiring Diagrams (tp6913)

Out on construction sites or event jobs, these Kohler 35‑175REOZT4 mobile generators spend their lives being dragged around, plugged into all sorts of temporary setups, and bounced over rough ground. This wiring diagram set is what I grab when I need to trace circuits, confirm connector locations, and make sure a repair or retrofit isn’t going to fry a control board. If, for example, the set won’t crank from the remote panel but starts fine locally, this is the document that lets me follow the start circuit, pin by pin, until I find the break or miswired connector.

Applications & Use Cases

• Verify wire routing and color codes after repairing a damaged harness or plug.
• Trace control and sensing circuits to isolate no‑start, no‑output, or nuisance shutdown issues.
• Confirm correct connector pinouts when installing or replacing controllers, switches, or remote panels.
• Plan and test add‑on wiring such as telemetry, alarms, or customer‑side interlocks without guessing.
• Perform continuity checks to prove a circuit before applying power after major electrical work.

FAQ

Q: Can I use this on a tablet in the field?

A: Yes, it works well on a tablet; you can zoom in on connector details and wire labels while you’re at the machine.

Q: Is it worth printing any pages?

A: Many techs print the key diagrams in large format and laminate them so they can mark routes and notes right at the genset.

Safety Note

Always de‑energize and lock out the generator before opening panels or disconnecting any wiring, even for simple continuity tests.
