Kubota LA302 Front Loader Parts Manual

The Kubota LA302 is a compact front loader that was commonly hung on smaller B‑series tractors back in the day. The Kubota LA302 parts manual is what parts counters, farm owners, and independent shops grab when they’re trying to see how the loader comes apart and what to order before pins seize or cylinders start weeping. If you’re planning a pin/bushing refresh, cylinder reseal, or need to replace bent loader arms or brackets, this parts manual, not a service manual, is the right style of book.

What this manual helps you do

• Identify every OEM Kubota part number on the LA302 loader frame, boom arms, crossmembers, and mounting brackets so you can order the exact pieces, not guess from photos.
• Locate the correct pins, bushings, shims, and hardware for the pivot points, quick‑attach (if fitted), and bucket linkage when tightening up a sloppy loader.
• Look up the proper seal kits, rods, and related components for the LA302 lift and bucket cylinders before you tear them down on the bench.
• Cross-reference older Kubota LA302 part numbers to newer superseded numbers shown in the catalog so the dealer can actually supply what you need.
• Verify quantity-per-loader for bolts, washers, and small bits so you don’t come up one bolt short halfway through reassembly.

Who this is for

This parts manual is aimed at an independent ag mechanic, farm owner-operator, or Kubota dealer parts staff who already knows how to wrench but needs the right numbers and exploded views. If you’re hunting for torque specs, hydraulic pressure checks, or step‑by‑step repair procedures, you want the Workshop/Service Manual instead, not this parts catalog.

FAQ

Q: Does this cover the hydraulics and cylinders on the LA302 loader?

A: Yes, a Kubota LA302 parts manual typically shows exploded diagrams and part numbers for the loader’s hydraulic cylinders, valves, hoses, and hard lines specific to the loader.

Q: Are the part numbers in this manual the latest ones Kubota uses?

A: The manual usually shows superseded numbers where Kubota updated parts, but your dealer’s system is the final word on the most current part number.

Bottom line: If you already know how to fix the loader and just need clear diagrams and Kubota LA302 part numbers, this is the right manual; if you need “how-to” instructions, keep looking for the WSM.

Table of Contents:

• Instructions for Parts Books
• LA302 Loader
• MAIN FRAME
• BRACE
• BOOM
• CONTROL VALVE
• CONTROL VALVE
• CONTROL VALVE
• CONTROL VALVE [COMPONENT PARTS]
• CONTROL VALVE [COMPONENT PARTS]
• CONTROL VALVE [COMPONENT PARTS]
• CONTROL LEVER
• CONTROL LEVER
• CYLINDER/HYDRAULIC HOSE
• HYDRAULIC HOSE(HYD.OUTLET BLOCK)
• HYDRAULIC TUBE
• CYLINDER (BOOM)[COMPONENT PARTS]
• CYLINDER (BUCKET)[COMPONENT PARTS]
• HYDRAULIC BLOCK
• HYDRAULIC BLOCK
• ACCESSORIES AND SERVICE PARTS

Browse all Kubota PDF Manuals
