Kubota TL720 Front Loader Workshop Manual

The Kubota TL720 is a front loader that hangs off the front of your tractor for lifting gravel, manure, brush, and pallet loads. People reach for this workshop manual when the loader is getting sloppy, leaking down, or something bends or breaks and you've only got a weekend to fix it. If you're trying to understand how the loader is built, how the hydraulics and linkage go together, and how to put it back safely, this is the kind of book you want in the shop.

What this manual helps you do

• Trace hydraulic circuits so you can find leaks, weak lift, or slow dump problems
• Check and adjust relief settings and linkage so the loader lifts and dumps correctly
• Follow step-by-step teardown and reassembly for cylinders, control valve, and pins/bushings
• Replace bent or worn structural parts with the right orientation and torque sequence
• Troubleshoot loader-specific issues like uneven lifting, bucket drift, and noisy operation

Who this is for

This is for an owner-operator, small contractor, or shop mechanic who is repairing or rebuilding a Kubota TL720 front loader, not just greasing it. If you need basic operating tips, safety info, or loader capacity charts, you want the operator's manual instead.

FAQ

Q: Is this a searchable PDF and are the diagrams readable?

A: Yes, these manuals are usually supplied as searchable PDFs and the hydraulic and exploded diagrams are clear enough to zoom in on at the bench.

Q: Will this cover my year of TL720 loader?

A: It's written for the TL720 loader model itself, which stayed pretty consistent, but you still need to confirm your loader tag says "TL720" and match the edition if noted.

Q: I'm just changing tractor fluids and filters, is this what I need?

A: No, this is loader-only repair information. For tractor engine, HST, or general maintenance, you need the tractor's own workshop and operator's manuals.

Bottom line: If you're wrenching on a Kubota TL720 front loader itself, this is the right manual. If your problem is with the tractor, this isn't the book you want.

Table of Contents:

A Kubota Front Loader workshop (service) manual generally covers the systems and service procedures listed below:

• Mechanism
  • Hydraulic Circuit
  • Hydraulic Block
  • Control Valve Assembly (Structure)
  • Control Valve Operation
  • Boom and Bucket Cylinders
• Servicing
  • General and Identification
  • Maintenance and Check Points
  • Troubleshooting
  • Servicing Specifications
  • Tightening Torques
  • Hydraulic Fittings
  • Mounting and Dismounting the Loader
  • Control Valve
  • Bucket, Boom and Hydraulic Cylinders
