The Liebherr LTM 1030-2.1 Mobile Crane spends its life lifting on tight sites where access is poor and downtime is expensive. When something’s not behaving, the first person who grabs a BMK / component identification manual is usually the tech trying to match a fault or schematic symbol to a real-world part. Knowing exactly where each component sits on the carrier and superstructure is what keeps diagnosis quick and avoids “parts changing by guesswork.” The Technical Information & BMK Components Manual for Liebherr LTM 1030-2.1 Mobile Crane provides component identification diagrams, reference designators, and visual outlines used by technicians cross‑referencing wiring or hydraulic schematics to physical parts on the crane.
What this manual helps you do
- Identify where a labeled component (like K-relays, valves, sensors) is physically mounted on the crane structure.
- Locate components on both carrier and superstructure using outline views and layout diagrams for SN 051226.
- Trace schematic reference designators (E, K, V, X numbers) to their real locations when working from wiring or hydraulic diagrams.
- Cross-reference Liebherr component names and IDs so you can talk the same language as the parts book and service information.
- Find and match components involved in a fault code to the actual hardware before you start disassembly.
Who this is for
This suits a workshop technician, field service tech, electrical diagnostic engineer, fleet mechanic, or training instructor teaching crane layout. If you need repair procedures, torque specs, or part numbers, you’re after a service manual or parts catalogue instead, not this BMK.
FAQ
Q: Are the component diagrams clear and searchable?
A: Yes, this kind of PDF BMK manual is normally high-contrast with zoomable, searchable text labels for component IDs.
Q: Does it cover both the carrier and the upper crane body?
A: Yes, it combines BMK information for the carrier (chassis/undercarriage) and the superstructure (upper crane, boom, winches, cab).
Q: Does it work together with other Liebherr documents?
A: Yes, the BMK component identification manual usually ties directly into Liebherr wiring diagrams, hydraulic schematics, service info, and parts catalogues via the same reference designators.
Bottom line: If your main goal is to find and identify components on an LTM 1030-2.1 (SN 051226) and link them to schematics, this is the right document. If you want how‑to repair steps or parts ordering data, it’s not.
📘 Show Index
Table of Contents:
Carrier — Table of Contents
- CARRIER
- TABLE OF CONTENTS
- BMK-Table (-A1 to -E16)
- BMK-Table (-E17 bis -L4)
- BMK-Table (-M1 to -S354)
- BMK-Table (-U50 to -Y43)
- BMK-Table (-Y44 bis -Y176)
- Carrier:
- ABV (antilocking system), transverse differential locks
- ABV (antilocking system), ASR (automatic track control)
- ABV (antilocking system), rear-axle release
- Supporting system, rear-axle steering
- Suspension
- Outside temperature sensor, batteries
- Lighting
- Lighting, outrigger control panels
- Coolant level
- Slewing pass-through
- Air drier
- Compact control block
- Pneumatic valves
- Horn
- Brake pressure sensor
- Driver's cab:
- Mirrors, interior lighting
- Operating elements
- Pneumatic system
- Heater, windscreen washer
- Centre console
- Fuses, diagnostic connector
- Additional heater
- Drive:
- Autom. transmission ZF Ergopower 6 WG-210
- Diesel engine OM 906 LA
- Air filter
- INDEX
- INDEX CARRIER
- -A 8
- -A 9
- -A10
- -A11
- -A12
- -A13
- -A17
- -A18
- -A19
- -A23
- -A24
- -A26
- -A32
- -A33
- -A50
- -A51
- -A64
- -A73
- -A74
- -A90
- -B 2
- -B 5
- -B 6
- -B 7
- -B 8
- -B 9
- -B10
- -B19
- -B31
- -B32
- -B33
- -B34
- -B37
- -B38
- -B39
- -B40
- -B41
- -B42
- -B43
- -B44
- -B45
- -E 1
- -E 2
- -E 3
- -E 4
- -E 5
- -E 6
- -E 7
- -E 9
- -E10
- -E11
- -E13
- -E14
- -E15
- -E16
- -E17
- -E18
- -E19
- -E20
- -E21
- -E24
- -E25
- -E27
- -E28
- -E29
- -E30
- -E31
- -E32
- -E33
- -E36
- -E37
- -E39
- -E40
- -E41
- -E42
- -E43
- -E44
- -E45
- -E46
- -E51
- -E52
- -E57
- -E58
- -E91
- -E92
- -E95
- -F 1 bis -F6
- -F 7 bis -F12
- -F13 bis -F18
- -F19 bis -F24
- -F25 bis -F30
- -F31 bis -F36
- -F37 bis -F42
- -F43 bis -F48
- -F49 bis -F54
- -F55 bis -F60
- -F61 bis -F66
- -F67 bis -F72
- -F79
- -F80
- -G1
- -G2
- -G3
- -G4
- -H101
- -H102
- -K50
- -K51
- -L1
- -L2
- -L3
- -L4
- -M 1
- -M 2
- -M 4
- -M10
- -M19
- -M20
- -M21
- -M22
- -M23
- -M24
- -M25
- -M26
- -M300
- -N1
- -P11
- -P14
- -R20
- -R22
- -R25
- -R26
- -R27
- -S 10
- -S 11
- -S 17
- -S 19
- -S82
- -S104
- -S105
- -S106
- -S114
- -S116
- -S118
- -S119
- -S121
- -S122
- -S123
- -S131
- -S134
- -S135
- -S137
- -S139
- -S142
- -S144
- -S146
- -S148
- -S151
- -S199
- -S313
- -S354
- -U50
- -X 47
- -X 49
- -X 50.1-6
- -X 57
- -X 74
- -X 75
- -X 76
- -X 81
- -X 99
- -X100
- -X101
- -X102
- -X104
- -X205
- -X207
- -X209
- -X210
- -X215
- -X266
- -X299
- -X329
- -XF1
- -XF2
- -XF3
- -XF4
- -XF5
- -XF6
- -XF7
- -XF8
- -XF9
- -XF10
- -XF11
- -XF12
- -Y 1
- -Y 2A
- -Y 2B
- -Y 3
- -Y 4
- -Y 5
- -Y 7
- -Y 9a
- -Y 9b
- -Y10
- -Y11
- -Y12
- -Y13
- -Y16
- -Y17
- -Y18
- -Y19
- -Y20
- -Y21
- -Y22a
- -Y22b
- -Y23
- -Y24
- -Y26a
- -Y26b
- -Y27a
- -Y27b
- -Y28a
- -Y28b
- -Y29a
- -Y29b
- -Y30a
- -Y30b
- -Y31a
- -Y31b
- -Y32a
- -Y32b
- -Y33a
- -Y33b
- -Y35
- -Y40
- -Y41
- -Y42
- -Y43
- -Y44
- -Y50
- -Y60
- -Y62
- -Y63
- -Y64
- -Y65
- -Y66
- -Y67
- -Y148
- -Y149
- -Y176
Superstructure — Table of Contents
- SUPERSTRUCTURE
- TABLE OF CONTENTS
- BMK-Table (-A1 to -M871)
- BMK-Table (-P2 to -T51)
- BMK-Table (-X1 to -Y139)
- Electrical equipment superstructure:
- Instruments, pedal, master switches
- Instruments roof console
- Heater Thermo 90S
- Screen washer, radio
- Relays
- Fuses, connectors
- Power pack, central unit, circuit boards, miscellaneous
- Hydraulic system superstructure:
- Air conditioning system
- Control strip
- Slewing gear valve, control block ballasting
- Öil cooler
- Hoist gear 1, ballasting
- Centralized lubricating system, tank sensor
- Horn, warning bell „cut-off LMB", emergency OFF cab
- Superstructure interlock
- Luffing ram
- Lighting superstructure and boom:
- Telescopic boom:
- Angle and length sensors
- Boom head
- INDEX
- INDEX SUPERSTRUCTURE
- -A1
- -A2
- -B1
- -B2
- -B4
- -B19
- -B25
- -B26
- -E1
- -E2
- -E6
- -E7
- -E17
- -E18
- -E96
- -E600
- -F1 to -F6
- -F7 to -F12
- -F8 to -F18
- -F9 to -F24
- -F25 to -F30
- -F31 to -F36
- -H80
- -H94
- -H95
- -H627
- -H628
- -H658
- -K1
- -K11
- -K12
- -K13
- -K14
- -K15
- -K16
- -K17
- -K18
- -K19
- -K20
- -K21
- -K22
- -K23
- -K24
- -K32
- -K33
- -K34
- -K651
- -K652
- -M2
- -M3
- -M4
- -M6
- -M7
- -M23
- -M871
- -P2
- -P654
- -P655
- -R4
- -S4
- -S26
- -S27
- -S28
- -S29
- -S30
- -S31
- -S82
- -S84
- -S89
- -S90
- -S91
- -S92
- -S199
- -S301
- -S320
- -S324
- -S326
- -S420
- -S422
- -S424
- -S426
- -S430
- -S602
- -S604
- -S606
- -S608
- -S610
- -S626
- -S630
- -S632
- -S634
- -S636
- -S638
- -S640
- -S642
- -S644
- -S648
- -S650
- -S656
- -S658
- -S871
- -S875
- -T51
- -X1
- -X2
- -X5
- -X10
- -X11
- -X14
- -X17
- -X18
- -X19
- -X20
- -X21
- -X22
- -X30
- -X33
- -X35
- -X37
- -X39
- -X49
- -XNOT
- -XST1
- -XST2
- -XST3
- -Y1
- -Y2
- -Y3
- -Y6
- -Y19a
- -Y19b
- -Y20
- -Y69
- -Y138
- -Y139
