Liebherr R 934 C and R 944 C Excavator Service Manual

Liebherr R 934 C and R 944 C excavators dig, load and move material on quarry floors, utility trenches and demolition sites. When one goes down out of warranty, the person with the wrench needs workshop procedures, not guesswork. That's usually a shop tech or fleet mechanic who is about to pull a pump, a swing drive or a final drive and wants the right steps in front of them. This manual covers the R 934 C, R 944 C and R 954 C in one document.

What this manual helps you do

• Diagnose hydraulic system faults using the hydraulic system and hydraulic components sections.
• Trace wiring and check circuits with the electrical system section.
• Rebuild a swing gear or swing ring, or replace travel gear and track components.
• Follow the diesel engine and coupling_splitterbox procedures when removing or servicing the drivetrain.
• Verify settings against the technical data section, and find the tools you'll need in the tools section.

Who this is for

A dealer technician, independent repair shop or rental fleet mechanic who repairs these excavators in-house. It also suits plant maintenance staff who keep a Liebherr machine running and want the workshop procedures on hand.

FAQ

Q: What do I receive and how is it organised?

A: You get 1 PDF file of 914 pages, in English. The text can be searched and copied, so you can jump straight to a component or term. Sections run from general information and technical data through engine, hydraulics, electrical, swing, travel, cab air conditioning and central lubrication.

Q: Which machines does it fit?

A: It is the R 934 C, R 944 C, R 954 C Service Manual, so it fits those three excavators.

Q: How does it fit the job I'm doing?

A: If you're removing, repairing or adjusting a component on one of these machines, the manual is laid out by system so you can open the relevant section and work through it. Special attachments, central lubrication and the cab heater and air conditioning system each have their own sections too.

Keep it on the shop computer or tablet, search the term you need, and get the machine back to work.

Click here to view the preview (PDF)

Models covered by this manual

This service manual is also used for one further Excavator model: R 954 C. Check the model and serial number on your data plate before ordering.

Table of Contents:

• general information
• tools
• technical data
• diesel engines
• coupling_splitterbox
• hydraulic system
• hydraulic components
• electrical system
• swing gear
• swing ring
• travel gear
• track components
• special attachments
• cab_heater_air conditioning system
• central lubrication
