The Liebherr LTM 1060-2 Mobile Crane earns its keep on tight sites where setup space is limited and you still need serious reach. When something electrical or hydraulic acts up, the first person grabbing a BMK (Bauteilkennzeichnung / component identification) manual is usually the tech with the laptop and multimeter. Component identification matters because if you can’t find “K15” or “V12” on the actual machine, the best wiring diagram in the world won’t save you. This Technical Information & BMK Components Manual for SN 057029 is built exactly for that kind of work, not for turning wrenches by guesswork.
What this manual helps you do
- Identify which physical component matches a reference like E1, K3, or X45 from your wiring or hydraulic diagrams.
- Locate sensors, valves, relays, switches, and control units on both the carrier and superstructure using outline views of the crane.
- Trace harness routes and junction box positions so you’re not stripping the wrong loom or chasing the wrong plug.
- Cross-reference fault codes and schematic items to Liebherr’s own component names and IDs.
- Pinpoint components during training so new techs learn the layout of the LTM 1060-2 Mobile Crane quickly and safely.
Who this is for
This is aimed at workshop technicians, field service techs, electrical diagnostic engineers, fleet mechanics, and training instructors who already have schematics or service data. If you need repair procedures, torque specs, pressures, or part numbers, you want the service manual and parts catalogue instead, not this BMK.
FAQ
Q: Are the diagrams clear and searchable in the PDF?
A: Yes, these BMK PDFs are normally clean scans or originals, and you can zoom in to read component IDs and use text search for designators.
Q: Does it cover both the undercarriage and the crane upper?
A: Yes, this BMK manual covers component identification on both the carrier and the superstructure for this machine.
Q: Does it tie in with other Liebherr documents?
A: Yes, the BMK is meant to be used alongside wiring diagrams, hydraulic schematics, service manuals, and parts catalogues by matching the reference designators.
Bottom line: If you’re trying to physically find and name components on a Liebherr LTM 1060-2 Mobile Crane, this is the right manual. If you’re trying to repair or order parts without other books, it’s not what you need.
