Tadano TR-250E Rough Terrain Crane Service Manual

A rough terrain crane like the TR-250E works on uneven job sites, with a telescopic boom and outriggers to set it up on poor ground. When one of these comes into the shop for a repair, the technician needs workshop procedures, not operating instructions. That's what a service manual is for: pulling a component, rebuilding it, adjusting it and testing it afterward.

What this manual helps you do

• Diagnose problems in the hydraulic pressure generating system before you start replacing parts.
• Rebuild outrigger, swing, elevating, winch and telescoping components by following the removal and repair procedures.
• Adjust and verify the safety devices after a repair.
• Troubleshoot the driving power generating and transmission systems.
• Check steering and brake system components when you service the carrier.

Who this is for

A crane service technician or rental fleet mechanic who is fixing a TR-250E in-house. It also suits independent repair shops and dealer technicians who need a workshop reference for a machine that arrived without paperwork.

FAQ

Q: What do I receive and how is it organised?

A: You get one PDF file of 377 pages, in English. It's arranged by chapter, from general cautions (Chapter A) through hydraulic pressure generating, outrigger, swing, elevating, winch, telescoping, safety devices, driving power generating, driving power transmission, steering and brake systems.

Q: Which machine does it fit?

A: It's the TR-250E Service Manual, publication number TR-250E(U)-1-R-01. The cover shows serial number 530119 and up, so check your crane's plate against that.

Q: How does it fit my repair job?

A: If you're tracing a fault, rebuilding a component or setting something back to spec after a repair, the chapters are split by system, so you can go straight to the one you're working on. Read the general cautions in Chapter A before you start.

Open the chapter for the system on your bench and work through the repair with the procedures in front of you.

Click here to view the preview (PDF)

Does this manual fit your machine?

The serial number shown is the one printed on the manual cover. Check the model and serial number on your machine's data plate before ordering.
