Takeuchi TW65 Wheel Loader Parts Manual (8020866) (SN E106266 REV 050912)

A TW65 wheel loader usually lives in the dirt—construction sites, yards, snow work, farm lanes—bouncing between piles and trucks all day. This parts manual helps you trace every assembly on that machine down to the last washer so you can order the right pieces the first time. Picture this: you’re halfway through a steering cylinder reseal, you crack a gland, and now you’ve got to identify the exact seal kit and backup rings instead of guessing from a blurry online photo.

Applications & Use Cases

• Track down the correct snap ring or shim in the transmission by following the exploded view and isolating the sub-assembly you’ve actually got on the bench.
• Verify you’re ordering the right variant of a hydraulic hose by checking how it routes through the frame and what fittings it mates to.
• Inspect a worn linkage pin, then match it to the diagram so you replace the pin, bushings, and any related seals in one shot.
• Check superseded part numbers when the dealer says your old number’s dead and you need to be sure the new one will align with your existing setup.
• Plan a rebuild by breaking the loader into sections—axles, steering hydraulics, working hydraulics—and test what you’ll need before you tear it apart.

FAQ

Q: Is this a searchable PDF or just page images?

A: It’s typically a PDF you can scroll and zoom; search works on most text, but I’d still learn the section layout and use the index like a real book.

Q: Can I print just the pages I need for the jobsite?

A: Yeah, you can usually print specific sections, then toss the greasy sheets when you’re done and keep the clean master file on your laptop or tablet.

Safety Note

Always bleed off hydraulic pressure and support raised components mechanically before you inspect, remove, or replace any TW65 parts.

Takeuchi TW65 Wheel Loader Index:

LIFTING UNIT 1
BASE FRAME 4
STEERING HYDRAULICS 10
WORKING HYDRAULICS 14
RETURN HYDRAULICS 16
DRIVING HYDRAULICS 18
HYDRAULIC LIFTING UNIT 20
HYDRAULIC QUICK RELEASE-1 22
PILOT CONTROL (COMPLETE) 26
SERVO CONTROL BRACKET 28
DIRECTIONAL VALVE 30
BRAKE THROTTLE VALVE 32
VALVE (COMPLETE) 34
WORKING RAM 36
LIFTING CYLINDER 38
STEERING CYLINDER 40
RETURN FILTER 42
ELECTRICAL SYSTEM 44
ELECTRICAL SYSTEM (CABIN) 48
PRINTED CIRCUIT BOARD 52
WORKING HEADLIGHT 54
TRACTION DRIVE 56
DIESEL ENGINE (COMPLETE) 58
EXHAUST SYSTEM 62
INCHING ACUTATOR 64
AIR FILTER SYSTEM 66
OIL PRESSURE PUMP (COMPLETE) 68
OIL PRESSURE PUMP (12V) 70
OIL PRESSURE PUMP (12V) (COMPLETE) 72
OIL MOTOR 74
FRONT AXLE 76
AXLE PIPE-1 80

AXLE PIPE-2 82
REAR AXLE 84
BRAKE DISK 88
REAR AXLE MULTIPLE DISK BRAKE 92
FUEL SYSTEM 96
DRIVERS SEAT 98
SEAT PART (LOWER) (COMPLETE) 100
CABIN 102
CABIN DOOR (LEFT) 108
LINING 110
WIPER SYSTEM 112
STEERING COLUMN (COMPLETE) 114
HEATING CIRCUIT 116
DECALS & ACCESSORIES 118
PROTECTIVE HOSES 122
COVERING-1 124
COVERING-2 128
ENGINE HOOD (COMPLETE) 130
WHEELS & TIRES 132
MAINTENANCE FILTER KITS 134
BLOCK HEATER 136
TW FILTER CHART 138
