Takeuchi TB128FR Mini Excavator Parts Manual (BF5Z001-7-0) (SN 12830003-)

On a TB128FR, you’re usually working in tight spots—around foundations, between houses, in muddy utility trenches. This parts manual helps you trace every component on that machine down to the last seal and snap ring so you can order the right stuff once, not three times. Say you’ve got the swing motor half stripped and you’re staring at two almost identical thrust washers—this book lets you follow the exploded view, match the part number logic, and verify which one actually fits your serial range.

Applications & Use Cases

• Track down the correct bucket linkage pins by tracing the boom/arm assemblies into their sub-groups instead of guessing from photos online.
• Isolate the right track roller or carrier roller by matching the undercarriage breakdown to your serial and build variation.
• Check hydraulic line routing so you can route and clamp a new hose exactly like factory and avoid rub-through later.
• Inspect the swing or travel motor breakdown to test, then replace only the failed seal kit or snap ring, not the whole assembly.
• Verify fasteners and small hardware when you’ve got a pile of bolts on the bench and don’t remember what length went where.

FAQ

Q: Is this a PDF I can search on my laptop or phone?

A: Yes, it’s typically a searchable PDF, so you can jump to sections by part name or number while you’re at the machine.

Q: Can I print just a few pages to take to the jobsite?

A: You usually can; most folks print the sections they’re working on so they don’t trash their laptop in the mud.

Safety Note

Always bleed off hydraulic pressure and support the attachment securely before you start pulling pins or cracking lines, no matter what the parts diagram shows.

Takeuchi TB128FR Mini Excavator Index:

• UNDERCARRIAGE 1
• LOWER FRAME 2
• CRAWLER BELT 4
• CRAWLER BELT (with rubber pads) 6
• CARRIER ROLLER 8
• TRACK ROLLER 10
• FRONT IDLER 12
• TRACK ADJUSTER 14
• TRAVEL DEVICE 16
• SLEW BEARING 18
• SWIVEL JOINT & ACCESSORIES 20
• DOZER BLADE 22
• PIPING; LOWER 24
• TURNTABLE & CONTROL LEVER 26
• SLEWING DEVICE 27
• TURNTABLE 30
• BOOM OFFSET (1/2) 34
• BOOM OFFSET (2/2) 38
• OFFSET SWITCH 40
• TRAVEL LEVER 42
• DOZER BLADE LEVER 44
• OPERATION LEVER & STAND 46
• PIPING; OPERATION LEVER (1/2) 50
• PIPING; OPERATION LEVER (2/2) 52
• PIPING; OPERATION LEVER (1/2) (ISO-JCB pattern) 54
• PIPING; OPERATION LEVER (2/2) (ISO-JCB pattern) 56
• ENGINE & ELECTRICAL SYSTEM 58
• ENGINE & ACCESSORIES (1/3) 59
• ENGINE & ACCESSORIES (2/3) 64
• ENGINE & ACCESSORIES (3/3) 68
• AIR CLEANER (for double element) 70
• DRAIN PLUG 72
• CONTROL BOX 74
• ENGINE CONTROL 76
• ELECTRICAL (1/2) 78
• ELECTRICAL (2/2) 80
