Format: PDF (Printable Document)
File Language: English
File Pages: 532
File Size: 36.61 MB (Speed Download Link)
Brand: Wacker Neuson
Model: DV60, DV90, DV100 Wheel Dumper
Type of Document: Service Manual
$ 45
Contents
1 Safety
1.1 Safety symbols and signal words
1.2 Qualification of personnel
1.3 Safety and accident prevention regulations
2 Preface
2.1 Notes about the document
2.2 Abbreviations and explanations
2.3 Tightening torques
2.4 Recovery
2.5 Restoration after recovery
3 Maintenance
3.1 Safety instructions for care and maintenance work
3.2 Special tools
3.3 Maintenance plan
3.4 Maintenance access covers
3.5 Vehicle fluids
3.6 Lubricate vehicle and attachments
3.7 Cleaning and care
3.8 Check screw connections
3.9 Engine maintenance
3.10 Exhaust gas after treatment
3.11 Servicing cooling
3.12 Servicing tires
3.13 Service transmission
3.14 Service axles
3.15 Brake system maintenance
3.16 Working hydraulics maintenance
3.17 Electrical system maintenance
3.18 Maintenance of heating and air conditioning system
3.19 Servicing the vehicle frame
3.20 Maintain central lubrication systemThe central lubrication system greases some lubrication points automatically.If the level is below the minimum, switch the central lubrication system to continuous operation and let it run continuously for 3 hours. Then select setting 2.
4 Engine
4.1 Overviews
4.2 Technical data
4.3 Malfunctions
5 Drive system
5.1 Components
5.2 Technical data
6 Brakes
6.1 Overviews
6.2 Components
6.3 Technical data
7 Vehicle frame
7.1 Overviews
7.2 Technical data
8 Hydraulics
8.1 Overviews
8.2 Components
8.3 Technical data
8.4 Faults in the hydraulic system
8.5 Hydraulic circuit diagrams
9 Electric
9.1 Overviews
9.2 Components
9.3 Technical data
9.4 Cable harnesses
9.5 Electrical circuit diagrams
10 Heating and air conditioning system
10.1 Overviews
10.2 Components
11 Lubrication system
11.1 Overviews
11.2 Components
11.3 Technical data
