Brand: Weidemann
Model: 1090 D-P Hoftrac, 1904 D-P Radlader
Book No: 5056190405
Type of Document: Parts Catalog
$ 45
These Weidemann 1090 D/P Hoftrac and 1904 D/P wheel loaders usually live in tight farm yards, stables, and small construction sites, doing pallet work, mucking out, and feeding. This parts catalog is what I’d open when I’ve got one parked in the bay with a leaking lift cylinder or a worn loader joint and I need to identify every seal, bushing, and bolt before ordering. For example, if a quick-attach linkage is sloppy, I use this book to trace the exact pin and bushing setup for that machine revision so I don’t end up with the wrong hardware.
Applications & Use Cases
FAQ
Q: Can I use this catalog on a tablet in the workshop?
A: Yes, it works well digitally; you can zoom in on exploded views to read part callouts more easily.
Q: Is it worth printing sections of this manual?
A: Many techs print just the assemblies they’re working on so they can mark notes and keep it next to the machine.
Safety Note
Always isolate the machine, support raised components securely, and follow Weidemann safety instructions before removing or refitting any parts.
9-10 Wichtige Hinweise Important Notices Notices Importantes Observaciones Importantes
12-13 Filtersatz filter set jeu de filtres juego de filtros
1 14-19 Vorder- und Hinterwagen Front and rear carriage Partie avant et arriere Parte delantera y trasera
2 20-23 Mittelgelenk Central joint Pivot Centrale Rótula central
3 24-29 Kabine Unterteil cabin lower part cabine partie inférieur cabina parte inferior
4 30-39 Kabine Oberteil cabin upper part cabina partie superior cabina parte superior
5 40-43 Fahrerschutzdach Driver’s Cap Cadre de Sécurité Cuadro de seguridad
44-45 Heizung I heating I chauffage I calefacción I
46-47 Heizung II heating II chauffage II calefacción II
6 48-49 Motorhaube Engine bonnet capot capó
50-55 Dämmatten insulating material materiel isolant material de insonorizacion
56-59 Schwinge MV laoding arm MV bras chargeur MV brazo de carga MV
7 60-63 Schwinge HV laoding arm HV bras chargeur HV brazo de carga HV
8 64-71 Motor engine moteur motor
72-75 Auspuff und Luftfilter exhaust and air filter echappement et filtre d’air escape y filtro de aire
76-77 Gasbetätigung accelerator accelérateur acelerador
78-79 Inchbetätigung inch control commande inch actividad inch
9 80-83 Kraftstofftank fuel tank réservoir de carburant depósito de carburante
página
Benennung parts name designation denominación
10 84-89 Elektrische Anlage I electric system diagramme I système électrique I sistema eléctrico I
90-91 Elektrische Anlage II electric system diagramme II système électrique II sistema eléctrico II
92-95 Armaturenlenksäule I Dashboard I Tableau de bord I Tablero de mando I
96-99 Armaturenlenksäule II Dashboard II Tableau de bord II Tablero de mando II
100-101 Stromlaufplan electrical wiring scheme de couplage diagrama de circuito
102-103 Hydrauliklaufplan hydraulic wiring diagramme scheme de couplage hydr. diagrame de circuito hidráulico
11 104-107 Verstellpumpe variable displacement pump pompe à débit variable bomba de caudal variable
108-117 Fahrhydraulik driving hydraulic transmission hydraul. transmission hidráulica
12 118-127 Lenkanlage I Steering system I Système de direction I Sistema de conducción I
128-137 Lenkanlage II Steering system II Système de direction II Sistema de conducción II
13 138-143 Hydraulikanlage MV Hydraulic system MV Système hydraulique MV Sistema hidráulica MV
144-153 Hydraulikanlage HV Hydraulic system HV Système hydraulique HV Sistema hidráulica HV
154-159 Kreuzsteuerventil Cross Steering valve distributeur hydraul. válvula de mando en cruz
14-15 160-165 Bremsanlage Brake system Système des freins Sistema de frenos
14 166-173 Achsantrieb vorn Front gear box Boite de vitesse av. Caja de cambios del.
15 174-181 Achsantrieb hinten Rear gear box Boite de vitesse ar. Caja de cambios tras.
185 Erdschaufel Bucket earth Godet Cuchara de tierra
186-193 Uni-Schaufel MV bucket MV godet MV cuchara MV
194-199 Uni-Schaufel HV bucket HV godet HV cuchara HV
200-201 Palettengabel Pallet forks Palettiseur Horquillas de palet
202-203 Palettengabel MV ISO FEM
ab 10/97
Pallet forks MV ISO FEM
From 10/97
Palettiseur MV ISO FEM
De 10/97
Horquillas de palet MV ISO FEM
Del 10/97
204-205 Palettengabel HV ISO FEM
ab 10/97
Pallet forks HV ISO FEM
From 10/97
Palettiseur HV ISO FEM
De 10/97
Horquillas de palet HV ISO FEM
Del 10/97
