Bobcat 853 Loader Service Manual (SN 510125001-510199999)

Format: PDF (Printable Document)

File Language: English

File Pages: 398

File Size: 10.41 MB (Speed Download Link)

Brand: Bobcat

Model: 853 Loader

Book No: 6720755

Serial No: SN 510125001-510199999

Type of Document: Service Manual

Categories: ,

$ 45

Share:

Bobcat 853 Loader Service Manual (SN 510125001-510199999)

The Bobcat 853 is an older skid-steer-class loader that still earns its keep on small jobsites, farms, and in rental yards. When one shows up in my truck route, the service manual is what I grab when a quick guess won't cut it. Owners and techs reach for this manual when they're chasing weird hydraulic issues, engine problems, or electrical gremlins and need the exact factory procedure, not guesses from a forum.

What this manual helps you do

  • Trace and diagnose hydraulic problems in the loader and drive system with factory test points and specs in front of you
  • Check and verify hydrostatic charge and case drain conditions before you start throwing expensive parts at it
  • Follow step-by-step teardown and reassembly of major components like drive motors, cylinders, and the Bob-Tach linkage in tight shop or yard space
  • Diagnose electrical and starting issues using wiring diagrams and connector callouts instead of poking around blind
  • Adjust and set linkages, control levers, and safety interlocks after repairs so the machine actually runs and locks out like it should

Who this is for

This manual is for anyone working on a Bobcat 853 loader in the serial range 510125001 to 510199999: small contractors, owner-operators, rental fleets, and shop or mobile techs. If you just want to learn how to run the machine or daily service points, you want the operator's handbook instead, not this.

FAQ

Q: Is this a searchable PDF, and can I read the wiring diagrams on a laptop or tablet?

A: These manuals are usually standard PDF files, so you can search text and zoom in on wiring diagrams without losing detail.

Q: How do I know if it matches my exact machine?

A: Check your loader's serial number plate. If it falls between 510125001 and 510199999, this is the right manual family.

Q: Is this the right document if I'm doing real repairs, not just maintenance?

A: Yes. This is the workshop service manual, meant for diagnostics and repair, not just fluid changes.

Bottom line: If your 853's serial number is in that range and you're actually wrenching on it, this is the manual you want in the truck or on the bench.
