Bobcat E10 Excavator Service Manual (SN A33P11001-A33P99999)

Format: PDF (Printable Document)

File Language: English

File Pages: 724

File Size: 22.95 MB (Speed Download Link)

Brand: Bobcat

Model: E10 Excavator

Book No: 6986788

Serial No: SN A33P11001-A33P99999

Type of Document: Service Manual

Categories: ,

$ 45

Share:

Bobcat E10 Excavator Service Manual (SN A33P11001-A33P99999)

On an E10, you're squeezing into tight backyards and inside buildings, doing trenching, footings, and utility work where a shovel just won't cut it. The service manual is what I grab on the laptop in the truck when I'm chasing a hydraulic issue or putting one back together after a hard failure. People buy this when the machine's out of warranty and they're tired of guessing at how things come apart or what to check next.

What this manual helps you do

  • Diagnose no-start or hard-start complaints on the small diesel, then check the right systems in order
  • Trace hydraulic problems like weak boom, slow travel, or dead auxiliary circuit, and pressure-test safely
  • Follow step-by-step teardown and reassembly for major components like cylinders, drive motors, and swing gear
  • Check and set adjustments for controls, pilot lines, and travel functions so the machine tracks straight and responds right
  • Replace and correctly route wiring, sensors, and switches using readable electrical and hydraulic schematics

Who this is for

This is for a small contractor, rental fleet, owner-operator, or shop mechanic who actually turns wrenches and wants factory repair procedures. If you only need basic controls, daily checks, or warning light meanings, you want the operator's handbook instead, not this manual.

FAQ

Q: Is this a searchable PDF and are the wiring diagrams readable?

A: Yes, it's a PDF you can search on a laptop or tablet, and the diagrams are meant to be zoomed so you can follow circuits in the field.

Q: Does it match my machine's serial number?

A: It's written for E10 excavators in the A33P11001 to A33P99999 serial range. If your tag is outside that range, this isn't the right one.

Q: Is this the right document if I'm doing my own repairs?

A: Yes, if you're doing real diagnostics and component repairs. If you only need parts numbers, you'd want the parts catalog instead.

Bottom line, if you own or service an E10 in that serial range and plan to actually fix it, this is the right manual. If you're just learning to run it, it's the wrong book.

📘 Show Index

Table of Contents:

  • MAINTENANCE SAFETY
  • CONTENTS
  • FOREWORD
    • FOREWORD
    • SAFETY INSTRUCTIONS
    • FIRE PREVENTION
      • Maintenance
      • Operation
      • Electrical
      • Hydraulic System
      • Fueling
      • Starting
      • Spark Arrester Exhaust System
      • Welding And Grinding
      • Fire Extinguishers
    • SERIAL NUMBER LOCATIONS
      • Excavator Serial Number
      • Engine Serial Number
    • DELIVERY REPORT
    • EXCAVATOR IDENTIFICATION
  • SAFETY AND MAINTENANCE
    • LIFTING AND BLOCKING THE EXCAVATOR
      • Procedure
    • UPPERSTRUCTURE SLEW LOCK
      • Operation
    • LIFTING THE EXCAVATOR
      • Procedure
    • TRANSPORTING THE EXCAVATOR ON A TRAILER
      • Loading And Unloading
      • Fastening
    • FOLD-DOWN TOPS
      • TOPS Position
      • TOPS Approved
      • Lowering The Fold Down TOPS
      • Raising The Fold Down TOPS
    • TAILGATE
      • Opening And Closing The Tailgate
    • SERVICE SCHEDULE
      • Contents Of The Inspection Checkbook (Logbook)
    • AIR CLEANER SERVICE
      • Daily Check
      • Replacing The Filter Elements
    • ENGINE COOLING SYSTEM
      • Cleaning
      • Checking Level
      • Removing And Replacing The Coolant
    • FUEL SYSTEM
      • Fuel Specifications
      • Biodiesel Blend Fuel
      • Filling The Fuel Tank
      • Fuel Filter
      • Draining The Fuel Tank
      • Removing Air From The Fuel System
    • ENGINE LUBRICATION SYSTEM
      • Checking And Adding Engine Oil
      • Engine Oil Chart
      • Replacing Oil And Filter
    • HYDRAULIC SYSTEM
      • Checking And Adding Fluid
      • Hydraulic / Hydrostatic Fluid Chart
      • Removing And Replacing The Hydraulic Filter
      • Removing And Replacing Hydraulic Fluid
    • LUBRICATION OF THE EXCAVATOR
      • Lubrication Locations
    • TRAVEL MOTOR
      • Checking And Adding Oil
      • Removing And Replacing Oil
    • SPARK ARRESTER MUFFLER
      • Cleaning Procedure
    • ALTERNATOR BELT
      • Belt Adjustment
      • Belt Replacement
    • SEAT BELT
      • Inspection And Maintenance
    • CONTROL CONSOLE LOCKOUTS
      • Inspection And Maintenance
    • EXCAVATOR STORAGE AND RETURN TO SERVICE
      • Storage
      • Return To Service
    • STOPPING THE ENGINE AND LEAVING THE EXCAVATOR
      • Procedure
    • MOTION ALARM
      • Description
      • Inspecting
      • Adjusting Switch Position
    • REMOTE START TOOL KIT – MEL1563
      • Remote Start Tool – MEL1563
      • Service Tool Harness Communicator – MEL1566
    • REMOTE START TOOL (SERVICE TOOL) KIT – 7003031
      • Description
      • Remote Start Tool (Service Tool) – 7003030
      • Excavator Service Tool Harness – 6689747
      • Computer Service Tool Harness – 6689746
  • HYDRAULIC SYSTEM
    • HYDRAULIC / HYDROSTATIC SCHEMATICS
    • HYDRAULIC SYSTEM INFORMATION
      • Glossary Of Hydraulic / Hydrostatic Symbols
      • Troubleshooting The Hydraulic Circuit
      • Troubleshooting The Cylinder Circuit
      • Troubleshooting The Swing (Upperstructure Slew) Circuit
      • Troubleshooting The Travel Circuit
    • CYLINDER (BOOM)
      • Testing
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CYLINDER (ARM)
      • Testing
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CYLINDER (BOOM SWING)
      • Testing
      • Removal And Installation
      • Parts Identification (Earlier Models)
      • Disassembly (Earlier Models)
      • Assembly (Earlier Models)
      • Parts Identification (Later Models)
      • Disassembly (Later Models)
      • Assembly (Later Models)
    • CYLINDER (BUCKET)
      • Testing
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CYLINDER (BLADE)
      • Testing
      • Removal And Installation
      • Parts Identification (Earlier Models)
      • Disassembly (Earlier Models)
      • Assembly (Earlier Models)
      • Parts Identification (Later Models)
      • Disassembly (Later Models)
      • Assembly (Later Models)
    • CYLINDER (TRACK FRAME EXPANSION)
      • Testing
      • Removal And Installation
      • Parts Identification (Earlier Models)
      • Disassembly (Earlier Models)
      • Assembly (Earlier Models)
      • Parts Identification (Later Models)
      • Disassembly (Later Models)
      • Assembly (Later Models)
    • VALVE (MAIN RELIEF)
      • Testing And Adjusting
    • VALVE (PORT RELIEF)
      • Testing And Adjusting
    • VALVE (PRESSURE REDUCING)
      • Testing And Adjusting
    • HYDRAULIC CONTROL VALVE
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Left Travel Valve Section Disassembly And Assembly
      • Slew Valve Section Disassembly And Assembly
      • Arm Valve Section Disassembly And Assembly
      • Boom Swing Valve Section Disassembly And Assembly
      • Auxiliary Valve Section Disassembly And Assembly
      • Blade Valve Section Disassembly And Assembly
      • Bucket Valve Section Disassembly And Assembly
      • Boom Valve Section Disassembly And Assembly
      • Right Travel Valve Section Disassembly And Assembly
      • Assembly
    • HYDRAULIC PUMP
      • Description
      • Testing The Hydraulic Pump
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • MANIFOLD ASSEMBLY / ACCUMULATOR
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • TRAVEL MOTOR
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • SWIVEL JOINT (S/N 133P14286 & ABOVE, B4K911001 & ABOVE AND B4PD11001 & ABOVE)
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • SWIVEL JOINT (S/N A33P13634 – A33P14285)
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • SWIVEL JOINT (S/N A33P12838 – A33P13633)
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • SWIVEL JOINT (S/N A33P11001 – A33P12837)
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • SWING MOTOR
      • Description
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CONTROL PATTERN SELECTOR VALVE
      • Description
      • Removal And Installation
      • Disassembly And Assembly
    • CONTROL LEVER (JOYSTICK) (RIGHT) (S/N A33S13155 & ABOVE, B4K911001 & ABOVE AND B4PD11001 & ABOVE)
      • Description
      • Testing
      • Handle Removal And Installation
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CONTROL LEVER (JOYSTICK) (RIGHT) (S/N A33P11001 – A33P13154)
      • Description
      • Testing
      • Handle Removal And Installation
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CONTROL LEVER (JOYSTICK) (LEFT) (S/N A33P13155 & ABOVE, B4K911001 & ABOVE AND B4PD11001 & ABOVE)
      • Description
      • Testing
      • Handle Removal And Installation
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • CONTROL LEVER (JOYSTICK) (LEFT) (S/N A33P11001 – A33P13154)
      • Description
      • Testing
      • Handle Removal And Installation
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • HYDRAULIC RESERVOIR
      • Description
      • Removal And Installation
    • OIL COOLER
      • Description
      • Removal And Installation
    • ELECTRIC BLADE / TRACK EXPAND VALVE
      • Description
      • Block Removal And Installation
      • Solenoid Removal And Installation
      • Block Disassembly And Assembly
    • TRACK EXPAND VALVE
      • Description
      • Block Removal And Installation
      • Control Handle Removal And Installation
      • Block Disassembly And Assembly
    • BUILD-UP VALVE
      • Description
      • Removal And Installation
      • Disassembly And Assembly
    • TWO SPEED CONTROL VALVE
      • Description
      • Block Removal And Installation
      • Solenoid Removal And Installation
      • Block Disassembly And Assembly
  • UNDERCARRIAGE
    • BLADE
      • Description
      • Extension Removal And Installation
      • Blade Removal And Installation
    • TRACK UNDERCARRIAGE COMPONENTS
      • Description
      • Track Lug Height
      • Checking Tension
      • Adjusting Tension
      • Track Removal And Installation
      • Idler Removal And Installation
      • Idler Parts Identification
      • Idler Disassembly
      • Idler Assembly
      • Track Tensioner Removal And Installation
      • Track Tensioner Disassembly And Assembly
      • Roller Removal And Installation
      • Roller Parts Identification
      • Roller Disassembly
      • Roller Assembly
      • Removal And Installation Of Expandable Track Frame
    • TRACK MAINTENANCE
      • Track Damage Identification
    • SWING CIRCLE GEAR
      • Removal And Installation
  • UPPERSTRUCTURE AND SWING SECTION
    • UPPERSTRUCTURE
      • Description
      • Removal
      • Installation
    • TOPS
      • Removal And Installation
    • SEAT
      • Removal And Installation
    • RIGHT CONSOLE
      • Joystick Console Cover Removal And Installation
      • Gas Spring Removal And Installation
      • Compression Spring Removal And Installation
      • Lever Removal And Installation
      • Joystick Console Frame Removal And Installation
      • Joystick Console Frame Disassembly And Assembly
    • LEFT CONSOLE
      • Joystick Console Cover Removal And Installation
      • Gas Spring Removal And Installation
      • Compression Spring Removal And Installation
      • Lever Removal And Installation
      • Joystick Console Frame Removal And Installation
      • Joystick Console Frame Disassembly And Assembly
    • ENGINE SPEED CONTROL
      • Removal And Installation
      • Cable Removal
      • Cable Installation
    • BLADE CONTROL
      • Removal And Installation
      • Disassembly And Assembly
      • Two Speed Switch Removal And Installation
    • SWING LOCK
      • Removal And Installation
      • Disassembly And Assembly
    • RIGHT PEDAL AND LINKAGE
      • Pedal Removal And Installation
      • Linkage Removal And Installation
      • Linkage Disassembly And Assembly
    • TRAVEL CONTROLS
      • Right Hand Travel Control Removal And Installation
      • Right Hand Travel Control Disassembly And Assembly
      • Left Hand Travel Control Removal And Installation
      • Left Hand Travel Control Disassembly And Assembly
    • LEFT PEDAL AND LINKAGE
      • Pedal Removal And Installation
      • Control Linkage Removal And Installation
      • Control Linkage Disassembly And Assembly
    • FLOOR PANELS
      • Description
      • Left Floor Panel Removal And Installation
      • Right Floor Panel Removal And Installation
    • FUEL TANK
      • Removal And Installation
    • HORN
      • Removal And Installation
    • SWING FRAME
      • Description
      • Removal And Installation
      • Bushing Removal
      • Bushing Installation
      • Boom Pivot Bushing Removal
      • Boom Pivot Bushing Installation
    • BOOM
      • Description
      • Removal And Installation
    • ARM
      • Description
      • Removal And Installation
      • Arm To Boom Bushing Removal And Installation
      • Arm To Bucket And Bucket Link Bushing Removal And Installation
    • BUCKET
      • Removal And Installation
    • TAILGATE
      • Removal And Installation
      • Latch Removal And Installation
    • COUNTERWEIGHTS
      • Rear Counterweight Removal And Installation
      • Left Side Counterweight Removal And Installation
      • Right Side Counterweight Removal And Installation
    • SIDE COVERS
      • Upper Left Side Cover Removal And Installation
      • Upper Right Side Cover Removal And Installation
      • Lower Left Side Cover Removal And Installation
      • Lower Right Side Cover Removal And Installation
    • INSTRUMENT PANEL
      • Removal And Installation
      • Disassembly And Assembly
    • QUICK COUPLER (KLAC™ SYSTEM)
      • Troubleshooting
      • Daily Inspection
      • Removal And Installation
      • Parts Identification
      • Disassembly
      • Assembly
    • QUICK COUPLER (LEHNHOFF® SYSTEM)
      • Troubleshooting
      • Daily Inspection
      • Removal (MS03 And MS08)
      • Installation (MS03 And MS08)
      • Parts Identification (MS03)
      • Disassembly And Assembly (MS03)
      • Parts Identification (MS08)
      • Disassembly (MS08)
      • Assembly (MS08)
  • ELECTRICAL SYSTEM & ANALYSIS
    • ELECTRICAL SCHEMATICS
    • ELECTRICAL SYSTEM INFORMATION
      • Glossary Of Electrical Symbols
      • Troubleshooting
      • Description
      • Fuse And Relay Location / Identification
      • Fuel Timer Location / Identification
    • BATTERY
      • Location
      • Servicing
      • Removal And Installation
      • Using A Booster Battery (Jump Starting)
    • ALTERNATOR
      • Description
      • Tests
      • Alternator Output Test
      • Full Field Test
      • Alternator Regulator Test
      • Alternator Regulator Test With Voltmeter
      • Removal And Installation
      • Charging System Inspection
      • Parts Identification
    • STARTER
      • Removal And Installation
      • Parts Identification
      • Cleaning And Inspection
    • LIGHTS
      • Boom Light Removal And Installation
      • Light Bulb Removal And Installation
      • Light Switch Removal And Installation
    • MICROSWITCH
      • Testing Left Console Microswitch
      • Left Console Microswitch Removal And Installation
      • Testing Right Console Microswitch
      • Right Console Microswitch Removal And Installation
    • FUEL LEVEL SENDER
      • Removal And Installation
      • Testing
  • ENGINE SERVICE
    • ENGINE INFORMATION
      • Description
      • Specifications
      • Torque Values
      • Troubleshooting
      • Removal And Installation
      • Engine Mount Replacement
      • Compression – Checking
    • MUFFLER
      • Removal And Installation
    • AIR CLEANER
      • Removal And Installation
    • ENGINE COOLING SYSTEM
      • Radiator Removal And Installation
      • Water Pump Removal And Installation
      • Water Pump Disassembly And Assembly
      • Thermostat Removal And Installation
      • Thermostat – Checking
    • LUBRICATION SYSTEM
      • Oil Pan Removal And Installation
      • Oil Pump Removal And Installation
      • Oil Pump – Service
      • Engine Oil Pressure – Testing
      • Relief Valve
    • FUEL SYSTEM
      • Fuel Shutoff Solenoid Removal And Installation
      • Fuel Shutoff Timer Removal And Installation
      • Fuel Injection Pump – Checking
      • Fuel Injection Pump Removal And Installation
      • Fuel Injection Pump – Timing
      • Fuel Camshaft Removal And Installation
      • Fuel Camshaft Governor
      • Fuel Injector Removal And Installation
      • Fuel Injector Nozzle Pressure – Checking
      • Valve Seat Tightness
    • CYLINDER HEAD
      • Glow Plug Removal And Installation
      • Valve Clearance Adjustment
      • Valve Timing – Checking
      • Cylinder Head Removal And Installation
      • Cylinder Head Disassembly And Assembly
      • Cylinder Head – Servicing
      • Cylinder Head Top Clearance
      • Valve Guide – Checking
      • Valve And Valve Seat Reconditioning
      • Valve Spring
      • Valve Tappets
      • Rocker Arm And Shaft – Checking
    • CRANKSHAFT AND PISTONS
      • Piston And Connecting Rod Removal And Installation
      • Piston And Connecting Rod – Servicing
      • Cylinder Bore – Checking
      • Connecting Rod Alignment
      • Crankshaft And Bearings Removal And Installation
      • Crankshaft And Bearings – Servicing
    • CAMSHAFT AND TIMING GEARS
      • Timing Gearcase Cover Removal And Installation
      • Timing Gears Checking Backlash
      • Idler Gear And Camshaft Removal And Installation
      • Idler Gear And Shaft – Servicing
    • FLYWHEEL AND HOUSING
      • Removal And Installation
      • Hydraulic Pump Coupler Removal And Installation
      • Flywheel Removal And Installation
      • Rear End Plate Removal And Installation
  • SPECIFICATIONS
    • EXCAVATOR SPECIFICATIONS
      • Machine Dimensions
      • Working Range
      • Rated Lift Capacity
      • Performance
      • Function Time
      • Weights
      • Controls
      • Engine (S/N B4PD11001 & Above)
      • Engine (S/N B4K911001 & Above)
      • Engine (S/N A33P11001 & Above)
      • Electrical
      • Hydraulic System
      • Hydraulic Cylinders
      • Drive System
      • Traction
      • Track width, rubber, standard
      • Fluid Capacities
      • Cooling system
      • Instrumentation
      • Environmental
      • Temperature Range
    • TECHNICAL SERVICE GUIDE SPECIFICATIONS
      • Engine
      • Engine Torques
      • Cooling System
      • Excavator Torques
    • TORQUE SPECIFICATIONS FOR BOLTS
      • Torque For General SAE Bolts
      • Torque For General Metric Bolts
    • HYDRAULIC CONNECTION SPECIFICATIONS
      • O-ring Face Seal Connection
      • Straight Thread O-ring Fitting
      • Tubelines And Hoses
      • Flare Fitting
      • Port Seal Fitting
    • HYDRAULIC FLUID SPECIFICATIONS
      • Specifications
    • CONVERSIONS
      • Decimal And Millimeter Equivalents
      • U.S. To Metric Conversion Chart
    • SERVICE TOOLS REQUIRED
      • Remote Start Tools
      • Hydraulic Tools
      • Engine Tools
      • Electrical Tools
      • General Tools
      • HVAC Tools
  • ALPHABETICAL INDEX
  • SERVICE SCHEDULE SYMBOLS

Bobcat Software

Bobcat PDF Manuals

Related Manuals

0
    0
    Your Cart
    Your cart is emptyReturn to Shop
