Caterpillar NOL10N Order Picker Operator Manual (SWHOU-00011)

A Cat NOL10N is an electric order picker for case picking from an operator platform, moving through warehouse aisles and lifting the operator to stock locations. When one is stuck on a second-shift breakdown, warehouse maintenance techs, dealer technicians, and rental fleet mechanics reach for the manual to operate, inspect, adjust, and return the truck to service. It covers the NOL10N, NOL10NF, and NOL10NV models. This download is a two-publication set, not a single booklet.

What this manual helps you do

• Follow safe operating, battery-swap, and charger-bay procedures.
• Check the platform, gate interlocks, lift chains, mast, and related safety equipment.
• Trace wiring and electrical faults through the traction motor, hoist motor, controller, and truck systems.
• Diagnose alarm conditions and use the listed checks to isolate a fault.
• Adjust or replace service items during planned maintenance and breakdown repair.

Who this is for

This suits a warehouse maintenance tech, plant maintenance team, dealer technician, independent forklift shop, or rental fleet mechanic working on Cat electric order pickers. It is the operator manual set for the NOL10N family, while the companion chassis or workshop manual is also available for deeper repair work.

FAQ

Q: What do I receive, and how is it organised?

A: You receive two separate Cat PDF publications split by section. The files support on-screen zoom and printing, and the set has a real text layer, so you can search and copy text.

Q: Which trucks does it fit?

A: It covers Cat NOL10N, NOL10NF, and NOL10NV order pickers. That gives you the matching model family for this warehouse truck range.

Q: How does it fit the job I'm doing?

A: Use it for safe operation, system checks, battery and electrical work, alarms, platform equipment, and routine service decisions. It helps get the truck pulled out of the aisle and back before the next picking wave.

For these Cat order pickers, this is the correct manual set for day-to-day operation, inspection, and maintenance support.

Models covered by this manual

Caterpillar publication SWHOU-00011 is the factory operator manual for the NOL10N. The same publication covers 1 further order picker model: NOL10NV. The cover also lists NOL10NF. Check the model and serial number on your data plate before ordering.

Table of Contents:

• SWHOU-00011 – Operation & Maintenance Manual
  • Truck
  • Safety Instructions
  • Operating Environment
  • Operating Devices
  • Driving Instructions
  • Load Handling
  • Batteries
  • Maintenance
  • Service
  • Transportation and Storage
  • Troubleshooting
  • Technical Specifications
