Caterpillar EP20TCA Forklift Service Manual (99N19-60100)

On a real warehouse floor, the Cat EP20TCA is an electric counterbalanced truck used to move and place pallet loads. A rental fleet mechanic, plant maintenance tech, or dealer technician reaches for this manual when a truck needs scheduled service, fault tracing, adjustment, or repair. The goal is simple: get the machine checked, fixed, and ready for its next shift.

What this manual helps you do

• Trace electrical circuits, controls, and wiring faults.
• Check traction motor, controller, steering, brake, and charging systems.
• Follow procedures for the power train, axles, hydraulics, mast, and forks.
• Diagnose operating problems using service data and troubleshooting guidance.
• Adjust, replace, and verify truck components during workshop repairs.

Who this is for

This suits warehouse maintenance technicians, rental fleet mechanics, plant maintenance teams, dealer technicians, and independent forklift repair shops. It is a workshop service manual for the electric counterbalanced lift truck trade. The operator handbook is the companion volume, also available, for daily operating instructions.

FAQ

Q: What do I receive, and how is it organised?

A: You receive 2 separate Cat publications delivered as 19 PDF files, split by section, with 402 pages total. The files carry a real text layer, so you can search and copy text, then zoom or print the pages for shop use.

Q: Which trucks and serials does it cover?

A: It covers EP13TCA, EP15TCA/18TCA, and EP20TCA, including EP20TCA serial 288AD0001-up. That gives you the stated fit for this model family.

Q: How does it fit the repair work I'm doing?

A: Use it for scheduled maintenance, electrical diagnosis, hydraulic and mast work, drive-unit repairs, adjustments, and service-data checks. It is the book to have when the EP20TCA is in the bay and the hour-meter service or repair must be done correctly.

With this set, you can inspect, troubleshoot, and return the specified Cat electric trucks to service with the workshop information in hand.

Models covered by this manual

Caterpillar publication 99N19-60100 is the factory service manual for the EP20TCA, serial range 288AD0001-up. The same publication covers 3 further forklift models: EP13TCA, EP15TCA, EP18TCA. The cover also lists EP15TCA/18TCA. Check the model and serial number on your data plate before ordering.
