Tadano AML-M Load Moment Indicator Service Manual

The AML-M load moment indicator monitors crane loading and tells the operator how close the crane is to its rated limits. When it throws a fault, reads wrong, or needs a part swapped, the service manual is what you open. Shop techs and fleet mechanics use it to find the problem and put the system back in working order.

What this manual helps you do

• Diagnose faults using the troubleshooting section before you start pulling parts.
• Follow the disassembly and reassembly procedures when you remove or rebuild a unit.
• Verify the system against the test procedures and maintenance standards after a repair.
• Check the data table and the list of AML functions when you need to confirm what the system should be doing.
• Trace how the system is built and how it works from the construction and function section.

Who this is for

A crane service technician or rental fleet mechanic who is repairing an AML-M in-house will get the most from it. It also suits an independent repair shop or dealer technician working on a machine that came in with no paperwork.

FAQ

Q: What do I receive and how is it organised?

A: You get the set, 2 PDF files with 187 pages in total, in English (multilingual). The main manual is Publication R301-Z8-01 at 107 pages, and the second is Publication R401- 3-01 at 80 pages.

Q: Which equipment does it fit?

A: It is written for the Tadano AML-M load moment indicator. The title on the manual is "AML-M Load Moment Indicator Service Manual."

Q: How does it fit the job I'm doing?

A: If you're tracing a fault, replacing a component, or checking the system after a repair, the sections run in that order: construction and function, troubleshooting, disassembly and reassembly, then test procedures and maintenance standards. You can go straight to the part you need.

Download the set, open the troubleshooting section, and you can start working through the AML-M repair with the procedures in front of you.

Click here to view the preview (PDF)

Table of Contents:

• Publication R301-Z8-01 (107 pages)
• Publication R401- 3-01 (80 pages)
  • CONSTRUCTION AND FUNCTION
  • TROUBLESHOOTING
  • DISASSEMBLY AND REASSEMBLY
  • TEST PROCEDURES AND MAINTENANCE STANDARDS
  • LIST OF AML FUNCTIONS
  • DATA TABLE
